LAN&Data&Computer Cables 4pair UTP Cat5e Solid Strand

Hangzhou Risun Cable Co., Ltd.
  • Application：Local Communication Cable, LAN Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：PVC,PE,LSZH
  • Type：Cat 5
  • Material Shape：Round Wire
  • Conductor Type：Solid,Strand

Base Info

  • Model NO.：utp cat5e
  • Wire Core Material：Bare Copper Wire
  • Certification：CE, ISO, RoHS, CPR,SGS,ETL
  • Model：UTP Cat5e
  • Brand：Risun or OEM
  • Insulation：HDPE
  • UV.Fr.Wa：Available
  • No.of Conductor：8 Core, 4pairs
  • Indoor/Outdoor：PVC,PE,PVC+PE,PVC+PVC
  • N.W.：8.5kgs
  • G.W.：10kgs
  • Transport Package：305m,Wooden Reel,CTN.
  • Specification：CPR,ETL,CE,SGS,RoHS,ISO9001
  • Trademark：Risun or OEM
  • Origin：Hangzhou, China(Mainland)
  • HS Code：8544491100
  • Production Capacity：20000 Boxes , Mont

Description

ElongationMin. 300%Temperature Range-20 up to +75° CTensile StrengthMin 1.68kg/mm²



Electrical Properties:



Conductor ResistanceMax. 9.38 ohm/100mResistance UnbalanceMax. 2%Insulation Resistance150 ohm/KMMutual CapacitanceMax. 5600pF/100mCapacitance UnbalanceMax. 330pF/100mImpedance100+/-15 ohmSpark Test2000VVelocity of Propagation67%



Technical Performance:



          Attenuation         RL    Next        PS Next       (Mhz)          (dB/100M)        (dB)     (dB)      (dB/100m)       1MHz               2.0         20    65.3          63.5       4MHz               4.1         23    56.3          54.2       8MHz               5.8        24.5    52.4          50.5      10MHz               6.6         25    51.3          49.2      16MHz               8.2         25    49.3          47.4      20MHz               9.3         25    48.8          46.9      25MHz              10.4         24    45.3          43.4   31.25MHz              11.7         23    43.0          41.8     62.5MHz              17.0         21    39.2          37.2     100MHz              22.0         20    36.3          34.4



Packing:
UTP Cat5e Duplex Network Cable

RISUN has it's own style of carton artwork. A carton factory support us to supply the most suitable carton for you. Your brand and artwork is also available.



Production line:



UTP Cat5e Duplex Network Cable

RISUN has two complete production line. 10 thousands box of UTP Cat5e cable per month.
