Communication Wire 50ohm Coaxial Cable Rg58 Rg213 for CCTV Camera for Modern Router
Jiangsu Elesun Cable Co., Ltd.- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
Base Info
- Model NO.：RG58
- Type：Rg58
- Material Shape：Round Wire
- Conductor Type：Solid
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, CCC, UL
- Model：Rg58
- Brand：Elesun
- Material of Inner Conductor：Bare Copper
- Structure of Inner Conductor：1,0.90mm
- Material of Insulation：Solid PE
- Diameter of Insulation：2.95mm
- Material of Braiding(Shielding)：CCA, Bare Copper, Tinned Copper
- Structure of Braiding(Shielding)：96*0.12mm
- Material of Jacket：PVC
- Diameter of Jacket：5.0mm
- Working Temp：-40ºC,80ºC
- Impedance：50Ω±2
- Voltage：1900V
- Weight：40kg,Km
- Transport Package：500m,Roll,CTN
- Specification：38*38*30cm
- Trademark：ELESUN
- Origin：China
- HS Code：8544200000
- Production Capacity：10000m,Day
- Package size per unit product：38.00cm * 38.00cm * 30.00cm
- Gross weight per unit product：22.000kg
Description
RG58/U coaxial cable specificationsMaterial of Inner Conductor Bare Copper Structure of Inner Conductor 1/0.90mm Material of Insulation Solid PE Diameter of Insulation 2.95mm Material of Braiding(Shielding) CCA, Bare Copper, Tinned Copper Structure of Braiding(Shielding) 96*0.12mm Material of Jacket PVC Diameter of Jacket 5.0mm Working temp -40ºC/80ºC Impedance 50Ω±2 Voltage 1900V Weight 40KG/KM
