Aluminum Conductor Material and Overhead Application ABC Cable Shepherd

Henan Hongda Cable Co., Ltd.
  • Application：Construction, Overhead, Industrial, Power Station, Transformer Cable ABC Cable AAC Conductor 1,0AWG 2
  • Voltage：Low and Medium Voltage Cable
  • Current：AC Cable
  • Insulation Material：XLPE
  • Sheath Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：IEC 60502
  • Wire Core Material：Aluminum Conductor
  • Certification：ISO, CCC, CE, Aluminum Conductor Material and Overhead Applicati
  • Model：ABC Cable
  • Brand：Henan Hongda
  • Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
  • Outer Sheath Color：Black etc.
  • No. of Cores：3+1
  • Cross Section：3*16mm2+1*25mm2
  • Packing Length：According to Your Request
  • Long‐term Working Temperature：90°c
  • Max. Temperature in Short Circuit：160°c ,250°c
  • Rated Voltage：300,300V, 300,500V, 450,750V, 0.6,1kv,
  • Design Standard：IEC 60502-1, IEC 60502-2, IEC 60227, IEC 60228
  • Warranty：3 Year
  • Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
  • Transport Package：by Sea
  • Specification：Construction Application and Aluminum Conductor Ma
  • Trademark：HENAN HONGDA
  • Origin：China
  • HS Code：85444929
  • Production Capacity：3000

Description

Steel reinforced aluminium wire with XLPE insulated aerial cableFor aerial power transmission applicationFor aerial power transmission application able to bear moderate pulling force.
4.Construction:
Phase conductors :Round standed or compacted 1350-H19 aluminium or Copper conductor ,AAAC,ACSR
Neutral or messenger conductor :Round standed or compacted 6201 aluminium alloy or AAC ,ACSR
Street lighting conductor: Round standed or compacted Aluminium conductor
Insulation : LDPE ,HDPE,XLPE ,PVC ( UV-resistant)
Note: The above provisions can be changed as order
Overhead line wire (Aerial line) Technical parameterTNB Standard (IEC 60502) Aerial Bundled Conductor (ABC) Cables
Number of Cores     x Nominal Cross Section   Overall DiameterWeightMaximum Conductor ResistanceMinimum Breaking Load  Current Rating
No.×mm²mmKg/KmΩ/KmkNA

3x16+1x25 RM
19.0
290
1,91
4,0
107

3x25+1x25 RM
23.2
400
1,200
5,5
132

3x35+1x25 RM
25.6
500
0,868
8,0
165

3x50+1x35 RM
30.0
680
0,641
10,7
205

3x70+1x50 RM
34.9
920
0,443
13,7
240

3x95+1x70 RM
40.6
1270
0,320
18,6
290

3x120+1x70 RM
44.1
1510
0,253
23,2
334

3x150+1x95 RM
49.2
1870
0,206
28,7
389

3x185+1x120 RM
54.9
2340
0,164
37,2
467

3x25+1x25+1x16 RM
23.2
470
1,200
2,5
72

3x35+1x25+1x16 RM
25.6
560
0,868
4,0
107

3x50+1x35+1x16 RM
30.0
740
0,641
5,5
132

3x70+1x50+1x16 RM
34.9
980
0,443
8,0
165

3x95+1x70+1x16 RM
40.6
1330
0,320
10,7
205

3x120+1x70+1x16 RM
44.1
1580
0,253
13,7
240

3x150+1x95+1x16 RM
49.2
1940
0,206
23,2
334

3x185+1x120+1x16 RM
54.9
2410
0,164
2,5
72
