Aerial Bundle 4*16 ABC Power Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Overhead, Industrial, Power Station
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：PVC
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：BS 7870
- Wire Core Material：Aluminum Conductor
- Certification：ISO, CCC, CE
- Model：ABC
- Brand：Henan Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：4
- Cross Section：16mm2
- Packing Length：According to Your Request
- Long‐term Working Temperature：70°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：300,300V, 300,500V, 450,750V, 0.6,1kv
- Design Standard：BS 7870
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Warranty：Three Years
- Transport Package：by Sea
- Specification：0.6,1kv abc aerial bundle 4 core 35mm aluminum cab
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：3000
Description
XLPE
Neutral or messenger conductor :Round standed or compacted 6201 aluminium alloy or AAC ,ACSR
Street lighting conductor: Round standed or compacted Aluminium conductor
Insulation : LDPE ,HDPE,XLPE ,PVC ( UV-resistant)
Note: The above provisions can be changed as order
Overhead line wire (Aerial line) Technical parameter GB/T12527, GB/T1179 Standar
| Number of Cores x Nominal Cross Section | Overall Diameter | Weight | Maximum Conductor Resistance | Minimum Breaking Load | Current Rating |
| No.×mm² | mm | Kg/Km | Ω/Km | kN | A |
4x16 RM | 18,8 | 286 | 1,910 | 2,5 | 72 |
4x25 RM | 21,2 | 430 | 1,200 | 4,0 | 107 |
4x35 RM | 24,1 | 553 | 0,868 | 5,5 | 132 |
4x50 RM | 27,8 | 746 | 0,641 | 8,0 | 165 |
4x70 RM | 31,8 | 1.009 | 0,443 | 10,7 | 205 |
4x95 RM | 37,8 | 1.332 | 0,320 | 13,7 | 240 |
4x120 RM | 54,4 | 1.632 | 0,253 | 18,6 | 290 |
