• Model NO.：CYKY-J, O
• Material Shape：Round Wire
• Range of Application：Installation
• Certification：ISO9001, CCC
• Brand：Boan
• Rated Voltage：450,750 V
• Size Range：25-240 Mm2
• Class of Conductor：1
• Number of Cores：2-37
• Transport Package：Heated Steel-Wooden Drum,Steel Drum
• Specification：SGS
• Trademark：DingAn or OEM
• Origin：Jiangsu Yixing, China
• HS Code：8544492100
• Production Capacity：38000 Km,Year

Basic Info.

Model NO. CYKY-J, O Material Shape Round Wire Range of Application Installation Certification ISO9001, CCC Brand Boan Rated Voltage 450/750 V Size Range 25-240 Mm2 Class of Conductor 1 Number of Cores 2-37 Transport Package Heated Steel-Wooden Drum/Steel Drum Specification SGS Trademark DingAn or OEM Origin Jiangsu Yixing, China HS Code 8544492100 Production Capacity 38000 Km/Year

Product Description

CYKY-J, O 450/750V
PVC insulated and PVC sheathed power and control cable

Usage:
For fixed installation in interior premises, cable ducts, in the open air, in water as permitted by the local building regulations if no risk of any mechanical damage is to be expected

Construction:
1 Copper conductor, round solid (RE), round stranded (RM) resp. Sector-shaped stranded (SM)
2 Core insulation (PVC)
3 Inner covering (EPDM or plastic tape)
4 Sheath (PVC black, UV-resistant)

Rated voltage: 450/750 V
Working temperature: -15° C + 70° C
Lowest installation temperature: -5 ° C
Maximum short-circuit conductor temperature: +160oC

Bending radius (min. ): 10 x of cable
Flame retardant: EN 60332-1-2

Number and cross-sectional area of conductor	Approximate overall diameter	Approximate net weight of cables	Maximum conductor resistance at temperature 20
n x mm2	mm	kg/km	Ω/km
2x1,5	7,2	90	12,1
2x2,5	8,0	119	7,41
2x4	9,7	180	4,61
3x1,5	7,6	106	12,1
3x2,5	8,5	144	7,41
3x4	10,3	220	4,61
3x6	12,1	312	3,08
4x1,5	8,3	129	12,1
4x2,5	9,2	176	7,41
4x4	11,7	281	4,61
4x6	13,2	384	3,08
4x10	15,1	565	1,83
4x16	17,7	833	1,15
5x1,5	9,1	157	12,1
5x2,5	10,1	215	7,41
5x4	12,8	345	4,61
5x6	14,5	471	3,08
5x10	17,0	712	1,83
5x16	19,4	1030	1,15
7x1,5	10,2	204	12,1
7x2,5	11,7	293	7,41
12x1,5	13,7	341	12,1
12x2,5	15,2	474	7,41
19x1,5	15,9	493	12,1
19x2,5	18,2	712	7,41
24x1,5	19,0	637	12,1
24x2,5	21,2	895	7,41
37x1,5	21,6	909	12,1
