• Model NO.：AFI400 series
• Origin：Nanjing, China
• Production Capacity：300PCS,Month

800 to 1700nm (SM)
Recognizable signal type*
CW, 2kHz, 1kHz, 270Hz ±10%
Detector Type
InGaAs 2pcs
Fiber Type
0.9, 0.25, 2.0, 3.0 mm fiber
Sensitivity
+10 ~ -50dBm
Accuracy *
+10dB to -30 dBm (Continuous Wave)
+10dB to -25 dBm (Modulated Signal)
LED Indicator
Signal direction; signal frequency (2kHz/1kHz/270Hz); low battery
Visual Fault Locator
No
1mW
10mW
Storage Temperature
-20 -- +60 °C , < 90%RH
Operating Temperature
-10 -- +50 °C , < 90%RH
Power Supply
AA * 2
Size
230mm * 45mm * 45mm
Weight
About 200g


* at 20 ± 3 °C , indoor, 1550nm wavelength, 0.9mm fiber, with white coat, 270Hz, error < 5%,



* 0.25, 2.0, 3.0mm fiber, the performance at continuous wave will be lower



* 1KHz, 2KHz, the performance at modulated signal will be lower



* at 1310nm wavelength, the performance will be lower







Accessories



Standard
User's manual
1
Calibration certification
1Carrying bag
1
