Enamelled constantan wire cooper nickel Alloy CuNi44/CuNi45/CuNi40

Shanghai Tankii Alloy Material Co., Ltd.
  • Type：Insulated
  • Conductor Type：Solid
  • Application：Overhead, Heating
  • Conductor Material：Copper
  • Sheath Material：Crosslinking
  • Insulation Material：PVC

Base Info

  • Model NO.：constantan
  • Material Shape：Round Wire
  • Range of Application：Cold-Resistant
  • Certification：ISO9001, CE, CCC, RoHS
  • Brand：TANKII
  • Serves：Samll Order Accepted
  • Size：0.01-10mm
  • standard：GB,ASTM,JIS,BIS,DIN
  • surface：bright
  • Transport Package：in Spool
  • Specification：0.01-10mm
  • Trademark：TANKII
  • Origin：China
  • HS Code：85441100
  • Production Capacity：2000tons,Year

Description

ROHS DirectiveCdPbHgCr441%0.5-Bal-NDNDNDND
Mechanical PropertiesMax Continuous Service Temp400ºCResisivity at 20ºC0.49±5%ohm mm2/mDensity8.9 g/cm3Thermal Conductivity-6(Max)Melting Point1280ºCTensile Strength,N/mm2   Annealed,Soft340~535 MpaTensile Strength,N/mm3   Cold Rolled680~1070 MpaElongation(anneal)25%(Min)Elongation(cold rolled)≥Min)2%(Min)EMF vs Cu, μV/ºC (0~100ºC)-43Micrographic StructureausteniteMagnetic PropertyNon
Application of Constantan
Constantan is a copper-nickel alloy that contains specific minor amounts of additional
elements to achieve precise values for the temperature coefficient of resistivity. Careful
control of melting and conversion practices results in a very low level of pinholes at
ultra-thin thicknesses. The alloy is used extensively for foil resistors and strain gauges.

Enamelled constantan wire cooper nickel Alloy CuNi44/CuNi45/CuNi40
