Sm mm Ds Nzds Fusionadora De Fibra Optica Fusion Slicer
Hangzhou Softel Optic Co., Ltd.- Customized：Customized
- Condition：New
Base Info
- Model NO.：KL-500
- Use：FTTH
- Warranty Time：12 Month
- Splicer Time：9s
- MOQ：1PC
- Power：AC 100-240V with AC Adapter
- Battery：Inner Li-Battery (5200mAh)
- Weight：1.55kg Including Battery
- Splicer Heating Time：30s
- Size：25(L)*105(W)*113(H)mm
- HS Code：8515809090
- Production Capacity：1000PCS Per Month
- Package size per unit product：25.00cm * 105.00cm * 113.00cm
- Gross weight per unit product：2.000kg
Description
Applicable fibers
SM MM DS NZDS
Fiber diameter
Cladding diameter:80-150μm;Coating diameter:100-1000μm
Fiber aligning method
Meticulous,Core,Clad,Manual
Actual average splice loss
0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NZDS)
Typical splicing time
Typical 9 sec (standard SM fiber)
Tube typical heating time
Typical 30 sec
Storage of splice
result
4000 results, 20 parameter per result
Fiber image magnification
200X (X or Y view),50X (X and Y view)
Battery capacity
Typical 300 cycles (splice/tube heat with inner Li-battery)
Monitor
3.5 inch TFT color LCD monitor
Power supply
AC 100-240V with AC adapter inner Li-battery (5200mAH)
Dimension
25mm(L)×105mm(W)×113mm(H)
Fiber cleaved length
8-16mm (Coating diameter:250μm)
Fiber count
Single
Return loss
>60dB
Splicing mode
Auto Calibrate Normal Special
Splicing program
53 (templet), 40(user)
Protection sleeve length
60mm, 40mm
Tube heating program
9 (templet),24(user)
Tension test
2N
Electrode life
2500
Terminal
USB
Operating condition
0-5000m above sea level, -10-50° Max wind velocity of 15m/s
Weight
1.55Kg including battery
