Type 241 1.1 to 11kv Mining Cable Tinned Copper EPDM Insulation CPE Jacket Oil Resisted Rubber Portable Power Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Tinned Annealed Copper
- Sheath Material：Heavy Duty Pcp
- Insulation Material：ERP
Base Info
- Model NO.：Type 241
- Material Shape：Round Wire
- Range of Application：Continuous Miners, Pump Cable, and Power Supply
- Certification：ISO9001, CE, CCC, RoHS, VDE
- Brand：Fengda
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Description
Nominal Conductor Area
Strand Size
Insulation Thickness
Earth Conductor
Pilot Conductor
Thickness of Sheath Including
SC PCP
Layer
Nominal Overall Diameter
Nominal Weight
Strand Size
Thickness of Covering
Strand Size
Thickness of Covering
mm²
No/mm
mm
No/mm
mm
No/mm
mm
mm
mm
kg/100m
Type 241.1
6
84/0.30
1.5
18/0.30
1.0
24/0.20
0.8
3.8
28.5
106
10
77/0.40
1.5
27/0.30
1.0
24/0.20
0.8
3.8
31.1
127
16
126/0.40
1.6
42/0.30
1.0
24/0.20
0.8
3.9
34.1
164
25
209/0.40
1.6
66/0.30
1.0
24/0.20
0.8
4.2
37.9
208
35
285/0.40
1.6
90/0.30
1.0
24/0.20
0.8
4.4
41.2
254
50
380/0.40
1.7
120/0.30
1.0
40/0.20
0.8
4.9
45.9
328
70
203/0.67
1.8
39/0.67
1.0
40/0.20
0.8
5.3
52.2
480
95
259/0.67
2.0
39/0.67
1.0
40/0.20
0.8
5.8
56.7
600
120
336/0.67
2.1
42/0.67
1.2
40/0.20
0.8
6.3
62.7
710
150
427/0.67
2.3
54/0.67
1.2
40/0.20
0.8
6.7
68.3
865
185
518/0.67
2.5
63/0.67
1.4
40/0.20
0.8
7.3
74.9
1030
240
672/0.67
2.8
77/0.67
1.4
40/0.20
0.8
8.0
83.3
1300
300
854/0.67
3.0
98/0.67
1.4
40/0.20
0.8
8.7
91.2
1600
Type 241.3
16
126/0.40
3.0
42/0.30
1.0
24/0.20
0.8
5.0
43.8
249
25
209/0.40
3.0
66/0.30
1.0
24/0.20
0.8
5.3
47.7
315
35
285/0.40
3.0
90/0.30
1.0
24/0.20
0.8
5.6
51.1
376
50
380/0.40
3.0
120/0.30
1.2
40/0.20
0.8
6.0
55.2
450
70
203/0.67
3.0
39/0.67
1.2
40/0.20
0.8
6.4
60.3
576
95
259/0.67
3.0
48/0.67
1.2
40/0.20
0.8
6.8
63.8
675
120
336/0.67
3.0
60/0.67
1.2
40/0.20
0.8
7.2
69.1
810
150
427/0.67
3.0
77/0.67
1.2
40/0.20
0.8
7.6
73.8
952
185
518/0.67
3.0
91/0.67
1.4
40/0.20
0.8
8.0
79.2
1130
240
672/0.67
3.0
112/0.67
1.4
40/0.20
0.8
8.6
86.0
1380
300
854/0.67
3.0
144/0.67
1.4
40/0.20
0.8
9.1
92.6
1660
Type 241.6
16
126/0.40
5.0
42/0.30
1.4
24/0.20
0.8
6.1
54.9
365
25
209/0.40
5.0
66/0.30
1.4
24/0.20
0.8
6.4
58.8
440
35
285/0.40
5.0
90/0.30
1.4
24/0.20
0.8
6.7
62.2
509
50
380/0.40
5.0
120/0.30
1.4
40/0.20
0.8
7.1
66.2
592
70
203/0.67
5.0
39/0.67
1.4
40/0.20
0.8
7.4
71.2
727
95
259/0.67
5.0
48/0.67
1.4
40/0.20
0.8
7.9
74.8
835
120
336/0.67
5.0
60/0.67
1.4
40/0.20
0.8
8.3
80.2
990
150
427/0.67
5.0
77/0.67
1.4
40/0.20
0.8
8.6
84.6
1140
185
518/0.67
5.0
91/0.67
1.4
40/0.20
0.8
9.0
90.0
1311
240
672/0.67
5.0
119/0.67
1.4
40/0.20
0.8
9.6
96.8
1576
300
854/0.67
5.0
156/0.67
1.4
40/0.20
0.8
10.2
103.6
1900
Type 241.11
25
209/0.40
7.6
66/0.30
1.8
24/0.20
0.8
7.8
73.2
645
35
285/0.40
7.6
90/0.30
1.8
24/0.20
0.8
8.1
76.6
724
50
380/0.40
7.6
120/0.30
1.8
40/0.20
0.8
8.5
80.6
825
70
203/0.67
7.6
39/0.67
1.8
40/0.20
0.8
8.9
85.7
975
95
259/0.67
7.6
48/0.67
1.8
40/0.20
0.8
9.3
89.1
1088
120
336/0.67
7.6
60/0.67
1.8
40/0.20
0.8
9.7
94.4
1258
150
427/0.67
7.6
77/0.67
1.8
40/0.20
0.8
10.0
98.9
1423
185
518/0.67
7.6
91/0.67
1.8
40/0.20
0.8
10.4
104.2
1610
