- Model NO.：Ntscgewoeu
- Material Shape：Round Wire
- Range of Application：for Connection to Dredgers, Floating Docks, Pumps
- Certification：ISO9001, CE, CCC, RoHS, VDE
- Brand：Fengda
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Basic Info.
Model NO.
Ntscgewoeu
Material Shape
Round Wire
Range of Application
for Connection to Dredgers, Floating Docks, Pumps
Certification
ISO9001, CE, CCC, RoHS, VDE
Brand
Fengda
Color
Black Red Yellow, According to Voltage Level
Whether It Is Environmentally Friendly
Yes
Whether Quality Inspection
Provide Inspection Certificate
Standard
Customized According to Specified National Standar
OEM/ODM
Accepted
Core
Single Core and Multicore
Transport Package
Standard Export Packaging
Specification
International General Specifications
Trademark
Fengda
Origin
Tianjin, China(Mainland)
HS Code
8544492100
Production Capacity
100000/Day
Product Description
Applications
These cables are designed for operation in water for connection to dredgers, floating docks, pumps, etc., in applications where high mechanical stresses are to be expected, also suitable for use in sewage, salt water and brackish water at water depths of up to 500 m.
Standards
VDE 0250 Part 813
Dimensions and Weight
1.8/3KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|
| NO. ×MM^2 | MM | MM | KG/KM |
|---|
| 3×25+3×25/3 | 38.6 | 41.6 | 2480 |
| 3×35+3×25/3 | 42.5 | 45.5 | 3090 |
| 3×50+3×25/3 | 46.0 | 49.0 | 3750 |
| 3×70+3×35/3 | 49.2 | 52.2 | 4620 |
| 3×95+3×50/3 | 57.2 | 61.2 | 6200 |
| 3×120+3×70/3 | 60.9 | 64.9 | 7390 |
| 3×150+3×70/3 | 66.3 | 70.3 | 8830 |
| 3×185+3×95/3 | 69.4 | 73.4 | 10170 |
| 3×25+3×16/3E | 41.3 | 44.3 | 1180 |
| 3×35+3×16/3E | 43.9 | 46.9 | 1650 |
| 3×50+3×25/3E | 47.8 | 50.8 | 2310 |
| 3×70+3×35/3E | 52.5 | 56.5 | 3220 |
| 3×95+3×50/3E | 59.4 | 63.4 | 4335 |
| 3×120+3×70/3E | 65.5 | 69.5 | 5480 |
| 3×150+3×70/3E | 69.2 | 73.2 | 6800 |
| 3×185+3×95/3E | 72.2 | 76.2 | 8375 |
3.6/6KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|
| NO. ×MM^2 | MM | MM | KG/KM |
|---|
| 3×16/16 | 47.0 | 52.0 | 3240 |
| 3×25/25 | 50.0 | 55.0 | 3870 |
| 3×35/35 | 55.0 | 55.0 | 4780 |
| 3×50/50 | 59.0 | 64.0 | 5700 |
| 3×70/70 | 64.0 | 70.0 | 7000 |
| 3×25+3×25/3 | 44.7 | 47.7 | 3120 |
| 3×35+3×25/3 | 47.3 | 50.3 | 3600 |
| 3×50+3×25/3 | 52.2 | 56.2 | 4560 |
| 3×70+3×35/3 | 55.5 | 59.5 | 5470 |
| 3×95+3×50/3 | 59.8 | 63.8 | 6570 |
| 3×120+3×70/3 | 65.3 | 69.3 | 8090 |
| 3×150+3×70/3 | 68.9 | 72.9 | 9250 |
| 3×185+3×95/3 | 72.0 | 76.0 | 10600 |
| 3×25+3×16/3E | 46.0 | 49.0 | 3160 |
| 3×35+3×16/3E | 48.6 | 51.6 | 3640 |
| 3×50+3×25/3E | 54.0 | 58.0 | 4600 |
| 3×70+3×35/3E | 57.2 | 61.2 | 5510 |
| 3×95+3×50/3E | 63.8 | 67.8 | 6610 |
| 3×120+3×70/3E | 68.1 | 72.1 | 8130 |
| 3×150+3×70/3E | 71.8 | 75.8 | 9290 |
| 3×185+3×95/3E | 76.6 | 80.6 | 10840 |
6/10 KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|
| NO. ×MM^2 | MM | MM | KG/KM |
|---|
| 3×16/16 | 49.0 | 54.0 | 3450 |
| 3×25/25 | 54.0 | 59.0 | 4350 |
| 3×35/35 | 57.0 | 62.0 | 5050 |
| 3×25+3×25/3 | 46.4 | 49.4 | 3320 |
| 3×35+3×25/3 | 49.0 | 52.0 | 3810 |
| 3×50+3×25/3 | 54.0 | 58.0 | 4780 |
| 3×70+3×35/3 | 57.2 | 61.2 | 5700 |
| 3×95+3×50/3 | 61.5 | 65.5 | 6830 |
| 3×120+3×70/3 | 67.0 | 71.0 | 8360 |
| 3×150+3×70/3 | 70.7 | 74.7 | 9530 |
| 3×185+3×95/3 | 73.7 | 77.7 | 10890 |
| 3×25+3×16/3E | 47.8 | 50.8 | 3360 |
| 3×35+3×16/3E | 51.9 | 55.9 | 3850 |
| 3×50+3×25/3E | 55.5 | 59.5 | 4820 |
| 3×70+3×35/3E | 59.0 | 63.0 | 5740 |
| 3×95+3×50/3E | 65.5 | 69.5 | 6870 |
| 3×120+3×70/3E | 69.8 | 73.8 | 8400 |
| 3×150+3×70/3E | 73.5 | 77.5 | 9570 |
| 3×185+3×95/3E | 78.3 | 82.3 | 10930 |
8.7/15 KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|
| NO. ×MM^2 | MM | MM | KG/KM |
|---|
| 3×25+3×25/3 | 52.7 | 56.7 | 4050 |
| 3×35+3×25/3 | 55.3 | 59.3 | 4650 |
| 3×50+3×25/3 | 58.7 | 62.7 | 5390 |
| 3×70+3×35/3 | 63.8 | 67.8 | 6740 |
| 3×95+3×50/3 | 68.1 | 72.1 | 7870 |
| 3×120+3×70/3 | 71.7 | 75.7 | 9150 |
| 3×150+3×70/3 | 77.2 | 81.2 | 10770 |
| 3×185+3×95/3 | 80.2 | 84.2 | 12310 |
| 3×25+3×16/3E | 54.0 | 58.0 | 4090 |
| 3×35+3×16/3E | 56.6 | 60.6 | 4690 |
| 3×50+3×25/3E | 60.3 | 64.3 | 5430 |
| 3×70+3×35/3E | 65.5 | 69.5 | 6780 |
| 3×95+3×50/3E | 70.3 | 74.3 | 7910 |
| 3×120+3×70/3E | 76.4 | 80.4 | 9190 |
| 3×150+3×70/3E | 80.1 | 84.1 | 10810 |
| 3×185+3×95/3E | 83.1 | 87.1 | 12350 |
12/20 KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|
| NO. ×MM^2 | MM | MM | KG/KM |
|---|
| 3×25/25 | 66,0 | 72.0 | 6140 |
| 3×35/35 | 69.0 | 75.0 | 6900 |
| 3×25+3×25/3 | 57.0 | 61.0 | 4690 |
| 3×35+3×25/3 | 59.6 | 63.6 | 5260 |
| 3×50+3×25/3 | 64.8 | 68.8 | 6380 |
| 3×70+3×35/3 | 68.1 | 72.1 | 7370 |
| 3×95+3×50/3 | 72.4 | 76.4 | 8600 |
| 3×120+3×70/3 | 77.9 | 81.9 | 10290 |
| 3×150+3×70/3 | 81.5 | 85.5 | 11560 |
| 3×185+3×95/3 | 84.3 | 89.3 | 13000 |
| 3×25+3×16/3E | 58.3 | 62.3 | 4730 |
| 3×35+3×16/3E | 60.9 | 64.9 | 5300 |
| 3×50+3×25/3E | 66.4 | 70.4 | 6420 |
| 3×70+3×35/3E | 69.8 | 73.8 | 7410 |
| 3×95+3×50/3E | 76.4 | 80.4 | 8640 |
| 3×120+3×70/3E | 80.7 | 84.7 | 10330 |
| 3×150+3×70/3E | 84.2 | 89.2 | 11600 |
| 3×185+3×95/3E | 89.0 | 94.0 | 13040 |
14/25 KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|
| NO. ×MM^2 | MM | MM | KG/KM |
|---|
| 3×50/50 | 81.0 | 88.0 | 9600 |
| 3×70/70 | 86.0 | 93.0 | 11100 |
| 3×95/95 | 92.0 | 99.0 | 13020 |
| 3×25+3×25/3 | 64.4 | 68.4 | 5860 |
| 3×35+3×25/3 | 67.0 | 71.0 | 8390 |
| 3×50+3×25/3 | 70.4 | 74.4 | 7220 |
| 3×70+3×35/3 | 73.7 | 77.7 | 8720 |
| 3×95+3×50/3 | 79.8 | 83.8 | 9950 |
| 3×120+3×70/3 | 83.5 | 87.5 | 11380 |
| 3×150+3×70/3 | 88.7 | 93.7 | 13120 |
| 3×185+3×95/3 | 91.8 | 96.8 | 14770 |
| 3×25+3×16/3E | 65.7 | 69.7 | 5900 |
| 3×35+3×16/3E | 68.3 | 72.3 | 8430 |
| 3×50+3×25/3E | 72.0 | 76.0 | 7260 |
| 3×70+3×35/3E | 77.2 | 81.2 | 8760 |
| 3×95+3×50/3E | 82.0 | 86.0 | 9990 |
| 3×120+3×70/3E | 87.9 | 92.9 | 11420 |
| 3×150+3×70/3E | 91.6 | 96.6 | 13160 |
| 3×185+3×95/3E | 94.6 | 99.6 | 14810 |
18/30KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|
| NO. ×MM^2 | MM | MM | KG/KM |
|---|
| 3×70/70 | 93.0 | 100.0 | 12780 |
| 3×95/95 | 97.0 | 104.0 | 14350 |
| 3×25+3×25/3 | 69.6 | 73.6 | 7010 |
| 3×35+3×25/3 | 72.2 | 76.2 | 7440 |
| 3×50+3×25/3 | 77.4 | 81.4 | 8590 |
| 3×70+3×35/3 | 80.7 | 84.7 | 9670 |
| 3×95+3×50/3 | 84.8 | 89.8 | 11010 |
| 3×120+3×70/3 | 90.2 | 95.2 | 12890 |
| 3×150+3×70/3 | 93.9 | 98.9 | 14260 |
| 3×185+3×95/3 | 96.8 | 102.0 | 15780 |
| 3×25+3×16/3E | 70.9 | 74.9 | 7050 |
| 3×35+3×16/3E | 73.5 | 77.5 | 7490 |
| 3×50+3×25/3E | 79.0 | 83.0 | 8630 |
| 3×70+3×35/3E | 82.4 | 86.4 | 9710 |
| 3×95+3×50/3E | 88.8 | 93.8 | 11050 |
| 3×120+3×70/3E | 93.1 | 98.1 | 12930 |
| 3×150+3×70/3E | 96.8 | 101.8 | 14300 |
| 3×185+3×95/3E | 101.6 | 106.6 | 15820 |
20/35 KV
| NUMBER OF CORES×NOMINAL CROSS SECTION | MINIMUM OVERALL DIAMETER | MAXIMUM OVERALL DIAMETER | NOMINAL WEIGHT |
|---|
| NO. ×MM^2 | MM | MM | KG/KM |
|---|
| 3×70/70 | 102.0 | 110.0 | 14950 |
| 3×95/95 | 106.0 | 114.0 | 16540 |
| 3×95+3×50/3 | 95.0 | 102.0 | 13670 |
| 3×120+3×70/3 | 101.0 | 109.0 | 15760 |
