Nyy 2.5mm2 Mica Tape Wrap Nickel Plated Copper Fiberglass Braided High Temperature Wire Aluminium Control Electric Coaxial Waterproof Rubber Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Car, Installation in Ground, Indoors, Outdoors.
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：PFA (Perfluoroalkoxy)
- Sheath Material：Glass Fibre Braid with a Heat Resistant Varnish
- Material Shape：Round Wire
Base Info
- Model NO.：Intemp 250 Generally to BS G210 Cable
- Wire Core Material：Class 5 Flexible Nickel-Plated Copper Conductor
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：Intemp 250 Generally to BS G210 Cable
- Brand：Feiya
- OEM&ODM：Yes
- Rated Voltage：0.6,1kv
- Operating Environment：Operate Under More Arduous High Temperature Condit
- Other Service：Can Be Customized
- Colors：Can Be Customized
- Armour/Earth Conductor：Providing Moisture Resistance, Toughness
- Temperature Rating：-75 to +250
- Separator：Mica Tape
- Transport Package：Wooden Box Packing or Pallet Shipping Containers
- Specification：nickel-plated copper conductor
- Trademark：Feiya
- Origin：China
- HS Code：8544
- Production Capacity：80000 Meter,Meters Per Month
Description
APPLICATION
This high performance cable is designed to operate under more arduous high temperature conditions, providing moisture resistance, toughness, flexibility and a continuous conductor operating temperature of 250ºC.
CHARACTERISTICS
Voltage Rating
Uo/U 0.6/1kV
Temperature Rating Fixed:
-75ºC to +250°C
Minimum Bending Radius Fixed:
10 x overall diameter
CONSTRUCTION
Conductor
Class 5 flexible nickel-plated copper conductor
Insulation
PFA (Perfluoroalkoxy)
Separator
Mica tape
Sheath
Glass fibre braid with a heat resistant varnish
