Fast Measurement 1310/1550/1625nm Fiber Cable Mni Palm OTDR Price

Hangzhou Softel Optic Co., Ltd.
  • Type：Module Connecting Machine
  • Customized：Non-Customized
  • Condition：New
  • Feature：Moistureproof
  • Product Name：Mini OTDR
  • Application：Optical Fiber Network

Base Info

  • Model NO.：AE2300
  • Distance：3m~160km
  • Pulse Width：3ns~20μs
  • Operating Humidity：5%~90%
  • Loss Resolution：0.001dB
  • Distance Resolution：0.05m
  • Linearity：0.04dB,dB
  • Display：4.3′′ 16:9 TFT Touch Screen
  • Dimensions：52mm(H)X94mm(W)X120mm(D)
  • Transport Package：Each Pair Per Box. Outdoor Brown Box
  • Specification：Grade A
  • Trademark：SOFTEL
  • Origin：Zhejiang Province, China
  • HS Code：85176229
  • Production Capacity：3000pairs,Month

Description

<Softel>Fast Measurement 1310/1550/1625nm Fiber Cable Mni Palm OTDRRoger Wilson  TEL:+86 18758163256ParametersDistance3m~160kmPulse WidthAE2300L/AE2300: 5ns~20μs
AE2300H/AE2300P-1/AE2300P-2/AE2300P-3: 3ns~20μsMeasurement TimeUser-definedDistance Uncertainty±(1m +0.0005%×Distance + Sampling Resolution)Loss ThresholdAE2300L/AE2300: 0.05dB
AE2300H/AE2300P-1/AE2300P-2/AE2300P-3: 0.03dBLoss Resolution0.001dBDistance Resolution0.05mLinearity0.04dB/dBSampling Points128000General Display4.3'' 16:9 TFT Touch ScreenData Storage>4000Optical AdapterFC/PC, SC/PCInterfaceUSB, RJ45Power SupplyAC/DC Adapter, Input AC90-240V ±10%, Output 12VOperating Temperature-10 ºC ~ 50 ºCStorage Temperature-40 ºC ~ 85 ºCRelative Humidity<80%Weight<1kgBatteryLithium Battery; Charging <4 hours, Operating time >8 hoursAccessorySC/PC Adapter1AC Adapter 1Quick Operating Guide1Package Bag1DiscToolbox Software and User ManualOTDR Order Information Chart
ModelWavelength (nm)Dynamic Range
(dB)		Event DZ (m)Attenuation DZ(m)
AE2300L1310/155032/303<15
AE23001310/155034/321.5<8
AE2300H1310/155036/340.8<5
AE2300P-11310/1550/162536/35/350.8<5
AE2300P-21310/1550/165036/35/350.8<5
AE2300P-31310/1550/149036/35/350.8<5
