Xlpo Insulated Tinned Copper PV1-F UV Solar Panel PV Cable 6mm 4mm
Henan Hongda Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Connecting Photovoltaic System Inside and Outside
- Voltage：Low and Medium Voltage Cable
- Current：DC Cable
- Insulation Material：XLPE
- Sheath Material：Crosslinking
- Material Shape：Round Wire
Base Info
- Model NO.：PV1-F cable
- Wire Core Material：Stranded Tinned Copper Conductor
- Certification：ISO, CCC, SGS
- Model：PV Cable
- Brand：Hongda
- Rated Voltage U0/U：1,1 Kv AC; 1.5,1.5 Kv DC
- Maximum Voltage：1.2kv (AC), 1.8kv (DC)
- Short Circuit Temperature：200 C,5 Sec
- Transport Package：Reel or Drum
- Specification：1.5sqmm to 240sqmm
- Trademark：Hongda or as customer require
- Origin：China
- HS Code：8544422100
- Production Capacity：40km,Day, Depending on Specification
Description
Ammoniac resistantVery good resistance to oils and chemicals High wear and robust, abrasion resistant
Other specification can produce depending on customer require.
Why Choose Us ?
1. We have a large production base, and advanced production equipment
2. Have an competitive price and high quality
3. Excellent after-sale service
4. Free issue:packaging list,invoice
5. Powerful technology team
6. Strict quality assurance system and perfect testing means
7. Advanced process equipment
8. Delivery on time
9. Our cable sales to Middle East,Africa,Russia,Southeast Asia, etc.
10.We have a good reputation in the overseas
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 10-20 days if the goods are not in stock,
it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 30% T/T in advance,70% T/T balance before shipment
*In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
Any needs or question, please contact me Mobile:+86-13783451632 , we will be more pleasure to service you.
We are looking forward to your inquiry and nice cooperation.
Dimensions and Weight
| No. of Cores × Nominal Cross Section | No. of Stranding | Nominal Conductor Diameter | Nominal Insulation Thickness | Nominal Sheath Thickness | Nominal Overall Diamater | Nominal Weight |
|---|---|---|---|---|---|---|
| No. ×mm^2 | mm | mm | mm | mm | kg/km | |
| 1×1.5 | 30/0.25 | 1.58 | 0.70 | 0.80 | 5.4 | 40 |
| 1×2.5 | 50/0.25 | 2.04 | 0.70 | 0.80 | 5.9 | 50 |
| 1×4.0 | 56/0.30 | 2.59 | 0.70 | 0.80 | 6.6 | 70 |
| 1×6.0 | 84/0.30 | 3.17 | 0.70 | 0.80 | 7.4 | 80 |
| 1×10 | 78/0.40 | 4.07 | 0.70 | 0.80 | 8.8 | 130 |
| 1×16 | 128/0.40 | 5.22 | 0.70 | 0.90 | 10.1 | 200 |
| 1×25 | 199/0.40 | 6.51 | 0.90 | 1.00 | 12.5 | 290 |
| 1×35 | 279/0.40 | 7.71 | 0.90 | 1.10 | 14.0 | 400 |
| 1×50 | 396/0.40 | 9.00 | 1.00 | 1.20 | 16.3 | 550 |
| 1×70 | 360/0.50 | 10.8 | 1.10 | 1.20 | 18.7 | 750 |
| 1×95 | 475/0.50 | 12.6 | 1.10 | 1.30 | 20.8 | 970 |
| 1×120 | 608/0.50 | 14.2 | 1.20 | 1.30 | 22.8 | 1220 |
| 1×150 | 756/0.50 | 15.8 | 1.40 | 1.40 | 25.5 | 1510 |
| 1×185 | 925/0.50 | 17.4 | 1.60 | 1.60 | 28.5 | 1850 |
| 1×240 | 1221/0.50 | 20.4 | 1.70 | 1.70 | 32.1 | 2400 |
