Flame Retardant N2xy Cu Power Cable Marked in Different Colors

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded,Solid
  • Application：Installation
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：XLPE

Base Info

  • Model NO.：N2XY
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemN2XY CableConductorCopper (as client's required)InsulationXLPE (as client's required)Outer SheathPVC (as client's required)Specifications1.5mm2 up to 300mm2Nominal VoltageUo/U: 0.6/1KVTest Voltage4000VTemperature RatingDuring installation -5°C to +90ºC Fixed Installation: -20°C to +90°CMinimum Bending Radius12 x cable diameterColorOptionalCertificationCECharacteristicFlame-retardant
Environmental protectionApplicationThis cable is dedicated to industrial facilities and urban network power distribution systems with a rated voltage of 0.6/ 1kV and a frequency of 50HZ. Suitable for indoor fixed installation, laying in cable ducts, cable trays, direct buried and trenches, or used in outdoor environments under protection.
