Italian Standard Fg16r16 Hepr Insulation PVC Power Cable
ItemItalian Standard FG16R16 CableConductorFine wired copper conductor(as client's required)InsulationHEPR, hard ethylene-propylene-rubber(as client's required)Outer SheathPVC compound(as client's required)Nominal Voltage600/1000VTest voltage4000VTemperature RangeFlexing Temperature: 0°C to +90&
-
Japanese Standard Cvv-Swa 0.6/1kv Fire Resistant Anti-Interference Control Cable
ItemJapanese StandardCVV-SWA CableConductorCopper (as client's required)InsulationSpecial ThermoplasticInsulation (as client's required)Outer SheathSpecial Thermoplastic Sheath (as client's required)Core NumberMulti-coresSpecifications1.5mm2 up to 300mm2Nominal Voltage600/1000VTest Voltage3500VOpera
-
Y-Cy-Jz Hot Sale Transparent Low Voltage 8X0.75mm2 18X1.5mm2
ItemY-CY-JZ Hot Sale Transparent Low Voltage 8x0.75mm2 18x1.5mm2ConductorCopper wire bareInsulationPVCInner sheathPVCScreenBraided screen of tinned copper wires, approx. coverage 85%Outer SheathPVCNominal VoltageAC U0/U 300/500 VTemperature RangeFlexible -10°C to +80°CFixed -40°C to +80&
-
Twisted 2 Pair 1.5 mm2 Swa PVC Instrument Cable 2p X 1.5 mm2 Shielded Underground Telephone Cable
CONDUCTORAnnealed copper, sizes: 0.5mm² and 0.75mm² mulitistranded(Class 5), 0.5 mm², 1.0 mm² solid(Class 1), 1.5mm² or 2.5mm², multistranded(Class 2) to BS6360INSULATIONPE (Polyethylene) type 03 to BS6234PAIRINGTwo insulated conductors uniformly twisted together with a
-
Liyy Cable Flame-Retardant Environmental Protection Cable PVC Outer Sheathed 300V
ItemLiYY Data CableConductorBare Copper (as client's required)InsulationSpecial PVC (as client's required)Outer SheathSpecial PVC (as client's required)Specifications0.14mm2 up to 0.75mm2Nominal Voltage300VTest Voltage2000VTemperature Rating-5°C to +70ºCMinimum Bending Radius7.5 x cable dia
-
0.6/1kv Control Cable Fire Resistant Solid/Strand Cu Cvv-Swa Cable
ItemCVV-SWA CableConductorCopper (as client's required)InsulationSpecial ThermoplasticInsulation (as client's required)Outer SheathSpecial Thermoplastic Sheath (as client's required)Core NumberMulti-coresSpecifications1.5mm2 up to 300mm2Nominal Voltage600Test Voltage3500VOperating Temperature-10&ord
-
Ymhy-Kst Outdoor-Use Power and Control Cable Tkd Alternative Wires
ItemYMHY-KST Outdoor-use Power and Control Cable TKD Alternative WiresConductorBare copper strandInsulationPVCOuter SheathPVCNominal VoltageUo/U: 300/500 VTest Voltage2000 VOperat. temp. fixed min/max-40 °C / +55 °COperat. temp. moved min/max-30 °C / +55 °CTemp. at conductor+70 °
-
H07ZZ-F LSZH Rubber Flexible Cable 450/750V CE Standard
ItemH07ZZ-F LSZH Rubber Flexible CableConductorBare copper strandInsulationLSZHOuter SheathLSZHNominal Voltage450/750VMinimum Bending RadiusFixed: 4 x overall diameterFlexed: 6 x overall diameterTemperature RangeFixed: -20°C to +90°CFlexed: -5°C to +50°CColorOptionalCertificationCEAp
