Rz1-K (AS+) Mica Cable 0, 6/1 Kv 2X1.5mm2 2X70mm2 3G/4G 1.5mm2 3X240mm2
ItemRZ1-K(AS+) Mica CableConductorFlexible bare copper wiresInsulationXLPEFillerExtruded filler for multicore cablesOuter SheathHalogen free material based on a thermoplastic polyolefinCore NumberMulti-coresMaximum Conductor TemperaturesNormal operation 90ºCShort circuit (5 seconds max.) 250&or
-
Flexible Shielded Instrumentation and Control Cable Z1c4z1-K (AS) Cable 300/500V
ItemZ1C4Z1-K (AS) CableConductorFlexible bare copper wiresInsulationXLPEFillerLSZH Compound - inner sheathScreeningBare copper wire braidCoverage: 60% aprox.Outer SheathPVCCore NumberMulti-coresTemperature rangeFixed installation: -15°C to +70°CDuring installation: 0°C Min.Short-circuit
-
TUV Certified Fg16r16 Cable 0.6/1kv Water Resistant and Anti-Abrasive
ItemTUV Certified FG16R16 CableConductorFine wired copper conductor(as client's required)InsulationHEPR, hard ethylene-propylene-rubber(as client's required)Outer SheathPVC compound(as client's required)Nominal Voltage600/1000VTest voltage4000VTemperature RangeFlexing Temperature: 0°C to +90°
-
Highly Flexible Oz-Bl-Cy PVC Control Cable Electrical Wires 4X1.5mm2 41X0.75mm2
ItemOZ-BL-CY PVC Control Cable Electrical Wires 4x1.5mm2 41x0.75mm2ConductorCopper wire bareInsulationPVCWrappingFoilScreenBraided screen of tinned copper wires, approx. coverage 85%Outer SheathPVCNominal VoltageAC U0/U 300/500 VTemperature RangeFlexible -10°C to +80°CFixed -40°C to +80&
-
Tkd Alternative Trommelflex Ksm-S-K (N) Shtou-J Rubber Reeling Cable
ItemTROMMELFLEX KSM-S-K (N)SHTOU-J Rubber Reeling CableConductorBare copper strandInsulationRubber compoundInner sheathRubber compoundAnti-torsion braidWide-meshed polyester braidOuter SheathRubber compoundOperat. temp. fixed min/max -50 °C / +80 °COperat. temp. moved min/max-50 °C / +80
-
Shielded Cable Z1c4z1-K (AS) 300/500V TUV Certified
ItemShielded Cable Cerviflam Z1C4Z1-K (AS)ConductorBare copper strandInsulationXLPEScreenBare copper wire braidCoverage: 60% aprox.Outer SheathLSZHNominal Voltage300/500VTest Voltage2000VTemperature rangeFixed installation: -15°C to +70°CDuring installation: 0°C Min.Short-circuit (Max. 5
-
Tml N-F for Medium Mechanical Requirements 0.6/1 Kv
ItemTML N-F for Medium Mechanical Requirements 0.6/1 kVConductorBare copper strandInsulationBased on VPEOuter SheathBased on EPRRated voltageUo/U: 0.6/1 kVTesting voltage3 kVNominal VoltageUo/U: 300/500 VOperat. temp. fixed min/max-50 °C / +60 °COperat. temp. moved min/max-40 °C / +60 &d
-
Shanghai Cable Manufacturing U-1000 R2V 0.6/1kv Flame Retardant Power Cable
ItemU-1000 R2V Flame Retardant CableConductorStranded copper conductor(as client's required)InsulationXLPE (as client's required)Outer SheathPVC (as client's required)Nominal Voltage0.6/1KVTemperature RangeDuring installation -10°C to +50ºCFixed installation: -25°C to +90°CMinimum B
