PVC Liycy Siaf Gl - Multi Wire Conductor Single Core Fibreglass Braided Silicone Rubber Insulated Cable Aluminium Copper Control Electric Wire Coaxial Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Car, Installation in Ground, Indoors, Outdoors.
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：Silicone Rubber
- Sheath Material：Fibre Glass Braid
- Material Shape：Round Wire
Base Info
- Model NO.：SIAF GL
- Wire Core Material：Class 5 Flexible Tinnned Copper
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：Siaf Gl
- Brand：Feiya
- OEM&ODM：Yes
- Rated Voltage：300,500V 10mm2 and Above: 0.6,1kv, When Protected
- Operating Environment：Use in Environments Where Sustained Heat Resistan
- Other Service：Can Be Customized
- Colors：Can Be Customized
- Inner Sheath：Rubber Type GM1b.
- Armour/Earth Conductor：Concentric Earth Conductor as Tensile-Stress-Resis
- Other Type Name：Siaf-Gl,H05sj-K
- Transport Package：Wooden Box Packing or Pallet Shipping Containers
- Specification：tinnned copper
- Trademark：Feiya
- Origin：China
- HS Code：8544
- Production Capacity：80000 Meter,Meters Per Month
Description
APPLICATION
Designed for use in environments where sustained heat resistance is required, SIA and SIAF cables have heat resistant properties up to 180°C and can also be employed at temperatures as low as -60°C. These cables are low smoke zero halogen and are suitable for power plants, a wide range of industrial applications in processing, packaging, refrigeration, foundaries, air craft construction and ship building.
CHARACTERISTICS
Voltage Rating
Uo/U SIA: 300/500V
SIAF: 0.25mm2 to 6mm2 300/500V
10mm2 and above: 0.6/1kV
Temperature Rating Fixed:
-60°C to +180°C
Minimum Bending Radius Fixed:
4 x overall diameter
