Fig8 Cst Armored Aerial Outdoor 24 Core Optical Fiber Cable
Hangzhou Spring Electronics Co., Ltd.- Application：Communication
- Type：Multi-mode Fiber
- Connection Structure：Non
- Material Shape：Round Wire
- Allowed Lateral Pressure：100(N,100mm)<1000(N,100mm)
- Allowed Tensile Strength：1000N<10000N
Base Info
- Model NO.：fiber optical cable
- Core：Multicore
- Certification：RoHS, CE, ISO9001
- Brand：OEM
- Sheath Material：PVC
- Fiber Type：G.652D
- Transport Package：6000m Wooden
- Specification：Gel-filled
- Trademark：OEM
- Origin：Made in China
- Production Capacity：1000km,Month
Description
Fiber
Count
Nominal Diameter
(mm)
Nominal Weight
(kg/km)
Allowable Tensile Load
(N)
Allowable Crush Resistance
(N/100mm)
Short Term
Long Term
Short Term
Long Term
2~12
7.6*15.6
142
7000
4000
1000
300
>12
Note : This datasheet can only be a reference, but not a supplement to the contract. Please contact our sales people for more detailed information.
We produce and test cable comply with following standard
Mechanical Performance
Max Tension Performance
IEC 60794-1-2-E
Max. Operation Tension
IEC 60794-1-2-E1
Crush Test
IEC 6079 -1-2-E3
Impact Test
IEC 60794-1-2-E4
Repeated Bending
IEC 60794-1-2-E6
Torsion Test
IEC 60794-1-2-E7
Cable bend
IEC 60794-1-2-E11A
Attenuation Coefficient
ITU-T G.652
Structural Test
IEC-60793-1-20
Environmental Performance
Temperature Cycling
IEC 60794-1-2-F1
Water Penetration
IEC 60794-1-2-F5B
Filing Compound Flow
IEC 60794-1-E14
