Power Line Accessories Overhead Line Tools ABC Cable Insulated Tension Clamp
Henan Hongda Cable Co., Ltd.- Application：Construction, Overhead, Industrial, Power Station, 3 Cores ABC Aluminium Cable 3*50mm2 Sizes
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：BS 7870
- Wire Core Material：Aluminum Conductor
- Certification：ISO, CCC, CE, Aluminum Conductor Material and Overhead Applicati
- Model：ABC Cable
- Brand：Henan Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：3
- Cross Section：50 mm2
- Packing Length：According to Your Request
- Long‐term Working Temperature：90°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：300,300V, 300,500V, 450,750V, 0.6,1kv
- Design Standard：IEC 60502-1, IEC 60502-2, IEC 60227, IEC 60228
- Warranty：3 Year
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Transport Package：by Sea
- Specification：Aluminum Conductor Material and Overhead Applicati
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：3000
Description
Approx. weight of cableDiameter of Conductor Thickness of Insulation Thickness of Insulation Screen Thickness of Sheath Stranding No.×mm² mm mm mm mm No.×mm mm Kg/kmm
3x35
6.9
5.5
0.6
1.2
7/5.00
61.0
1780
3x50
8.1
5.5
0.6
1.2
7/5.00
63.3
1970
3x70
9.7
5.5
0.6
1.2
7/5.00
66.5
2260
3x95
11.4
5.5
0.6
1.2
7/5.00
69.9
2600
3x120
12.8
5.5
0.6
1.2
19/3.65
75.9
3070
3x150
14.2
5.5
0.6
1.2
19/3.65
78.7
3390
3x185
15.7
5.5
0.6
1.2
19/3.65
81.7
3760
3x35
6.9
5.5
0.6
1.2
7/5.00
61.0
1780
3x50
8.1
5.5
0.6
1.2
7/5.00
63.3
1970
3x70
9.7
5.5
0.6
1.2
7/5.00
66.5
2260
3x95
11.4
5.5
0.6
1.2
7/5.00
69.9
2600
3x120
12.8
5.5
0.6
1.2
19/3.65
75.9
3070
3x150
14.2
5.5
0.6
1.2
19/3.65
78.7
3390
3x185
15.7
5.5
0.6
1.2
19/3.65
81.7
3760
