Ho7rn-F Romex Cable High Density Elevator Plastic Cover Aluminium Control Electric Coaxial Waterproof Rubber PV Solar Panel Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Solid;Stranded or Flexible
- Application：Overhead, Heating, Underground, Building Wire
- Conductor Material：Copper or Aluminum
- Sheath Material：PVC
- Insulation Material：PVC
Base Info
- Model NO.：bv
- Material Shape：Round Wire
- Range of Application：Indoor Power Supply of Electric Appliances
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Fengda
- OEM：Yes
- Packing：100m,Roll
- Color：Black, Red, Yellow, Blue or Customized
- Rated Voltage：300,500V 450,750V
- Armour：No
- Model Number：BV Bvvr BVV Blv
- OEM/ODM：Available
- Standard：Customized Based on Specified National Standard
- Core：Single Core and Multicore
- Whether Quality Inspection：Provide Inspection Certificate
- Whether It Is Environmentally Friendly：Yes
- Transport Package：Wooden Box Packing or Pallet Shipping Containers
- Specification：copper
- Trademark：Fengda
- Origin：China
- HS Code：8544
- Production Capacity：80000 Meter,Meters Per Month
Description
RVS PVC insulated twisted -pair flexible wire of 300/300V| Nominal section of conductor mm2 | 20ºC (≤)Ω/km At 20ºC,conductor resistance (≤)Ω/km | 70ºC≥MΩ.km At 70ºC ,the Min insulating resis-tance ≥(MΩ.km) | mm Max OD(MM) | kg/km Weight referred kg/km |
| 2×0.5 | 39.0 | 0.016 | 6.0 | 23 |
| 2×0.75 | 26.0 | 0.014 | 6.2 | 30 |
| 2×1.0 | 19.5 | 0.011 | 6.6 | 36 |
| 2×1.5 | 13.3 | 0.010 | 7.2 | 49 |
| 2×2.5 | 7.98 | 0.009 | 8.2 | 76 |
| 2×4 | 4.95 | 0.007 | 9.5 | 114 |
| 2×6 | 3.30 | 0.006 | 11.6 | 174 |
