• Model NO.：RG 6
• Brand：General Clad
• Dielectric Material：Foam PE
• Jacket Material：PVC
• Inner Shield (Braid) Coverage：60 %
• Inner Shield (Braid) Material：Aluminum
• Inner Shield (Tape) Material：Aluminum,Poly, Bonded
• Outer Shield (Braid) Coverage：40 %
• Outer Shield (Braid) Material：Aluminum
• Outer Shield (Tape) Material：Aluminum,Poly, Non-Bonded
• Transport Package：Packed by Carton,Wooden Drum,Wooden Pallet
• Trademark：Copper clad steel wire
• Origin：China
• Production Capacity：200km,Month

Cable TypeSeries 6Center Conductor Type                                                    Solid Construction TypeNon-armoredJacket Color                                                                         White/Black
DimensionsCable Length304.8 m | 1000 ftDiameter Over Center Conductor, specific0.0403 in per 1 strandDiameter Over Dielectric4.572 mm | 0.18 inDiameter Over Dielectric Tolerance±0.004 inDiameter Over Inner Shield (Braid)5.385 mm | 0.212 inDiameter Over Jacket Tolerance±0.008 inDiameter Over Jacket, nominal7.62 mm | 0.3 inDiameter Over Outer Shield (Braid)5.893 mm | 0.232 inCenter Conductor Gauge18 AWGInner Shield (Braid) Gauge34 AWGOuter Shield (Braid) Gauge34 AWG
Electrical SpecificationsCapacitance52.493 pF/m | 16 pF/ftCharacteristic Impedance75 ohmCharacteristic Impedance Tolerance±3 ohmConductor dc Resistance6.5 ohms/kft | 21.325 ohms/kmDielectric Strength, conductor to shield2500 VdcJacket Spark Test Voltage2500 VacNominal Velocity of Propagation (NVP)84 %Shield dc Resistance4.9 ohms/kft | 16.076 ohms/kmStructural Return Loss15 dB @ 1000-3000 MHz | 20 dB @ 5-1000 MHzStructural Return Loss Test Method100% Swept Tested
Material SpecificationsCenter Conductor MaterialBare copperDielectric MaterialFoam PEJacket MaterialPVCInner Shield (Braid) Coverage60 %Inner Shield (Braid) MaterialAluminumInner Shield (Tape) MaterialAluminum/Poly, bondedOuter Shield (Braid) Coverage40 %Outer Shield (Braid) MaterialAluminumOuter Shield (Tape) MaterialAluminum/Poly, non-bonded
Package
