• Model NO.：coaxial cable
• Wire Core Material：Tinned Wire
• Certification：CE, ISO, RoHS
• Model：HYAT-xx
• Applications：CCTV CATV System
• Models：Rg58 Coaxial Cable
• Impendence：50ohm
• Conductor：Tinned Copper
• Braiding：Tinned Copper
• Foam`：Solid
• Coat：PVC
• Transport Package：Packed by Carton,Wooden Drum,Wooden Pallet
• Specification：Local Communication Cable, Coaxial Cable, LAN Cab
• Trademark：FUU
• Origin：Made in China
• HS Code：8544200000
• Production Capacity：24000km,Year

Overview MIL-C-17 Coaxial Cable TYPE:RG58/U,RG58A/U,RG58C/UConstructionItemMaterialDiameter(mm)Center ConductorStrand Tinned Copper19/0.18DielectricSolid PE2.95Overall BraidTinner Copper Wire Braiding
95%/
 JacketPVC4.95
 Electrical Charateristics  Impedance(Ω)50Capacitance(pF/m)101Velocity of Propagation(%)66%Inner Conductor DCR(Ω/km)35.4Outer Conductor DCR(Ω/km)13.5Max Operating Frequency1000Operating Temp Range(ºC)(-40 to +85)Attenuation @68°F.(20 ºC )@Frequency(Mhz)Max Attenuation(dB/100ft)Max Attenuation(dB/100m)101.54.9503.310.91004.715.52007.524.540010.634.860012.139.686017.256.4100018.460.5

TheCompany Profile

FAQ

After Sales Service



Our Advantages



1) Quick Response --All inquiries will be replied within 24 hours.
   2) Professional Quotation --All prices will be quote according to customers' detailed
   specifications & requirements.
   3) OEM & ODM Service
   4) Can print your own brand on the jacket printing with foot or meter marking.
   5) Make customized designs for stickers, drums, outer cartons, etc.
   6) Stable Quality --All materials and products passed restrict QC procedures,comply with
   international standards.
   7) Fast Delivery --LCL orders,15days after confirmation; FCL orders, 20 days after
   Confirmation in usual.
