High Quality Sy LSZH Control Flexible LSZH Cable for Measuring Regulation

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：LSZH
  • Insulation Material：LSZH
  • Material Shape：Round Wire

Base Info

  • Model NO.：SY LSZH Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemSY LSZH Control CableConductorClass 5 flexible plain copperInsulationLSZH (Low Smoke Zero Halogen)BraidingGSWB (Galvanized Steel Wire Braid) minimum coverage of braiding shall be 50%Outer sheathLSZH (Low Smoke Zero Halogen)Core NumberMulticores (As client's requirement)Temperature range-15ºC to +70°CRated voltageUo/U 300/500VColorOptionalApplicationUsed as interconnecting cable for measuring, controlling or regulation in control equipment for assembly and production lines, conveyors and for computer units. Suitable for flexible use in conditions of light mechanical stress. Can be used outdoors when protected against direct sunlight, and in dry or moist conditions indoors. The braided screen offers mechanical protection and a level of electro-magnetic shielding. The galvanized coating helps protect against corrosion. For installations where fire, smoke emissions and toxic fumes create a potential risk to life and equipment.
