• Model NO.：AIRDAC CNE Cables
• Material Shape：Round Wire
• Range of Application：Service Connection Cable
• Certification：CCC
• Brand：Hongda
• Increased Safety：Reliable Earthing
• Lower Mass：Due to Smaller Diameter - No Steel Wire Armour
• Transport Package：Wooden
• Specification：16mm
• Trademark：hongda
• Origin：Henan,China
• HS Code：8544492100
• Production Capacity：20km,Day

Basic Info.

Model NO. AIRDAC CNE Cables Material Shape Round Wire Range of Application Service Connection Cable Certification CCC Brand Hongda Increased Safety Reliable Earthing Lower Mass Due to Smaller Diameter - No Steel Wire Armour Transport Package Wooden Specification 16mm Trademark hongda Origin Henan/China HS Code 8544492100 Production Capacity 20km/Day

Product Description

4mm, 10mm AIRDAC II CNE Cables house service connection cable


AIRDAC II CNE Cables

Description	Cable size	Phase Conductor Resistance (Ohm/km) DC @ 20 °C	Phase Core Impedance (Z) (Ohm/km)	Current Rating (A)*
4mm², AIRDAC II CNE Cable	4mm²	4,80	5,88	30
10mm², AIRDAC II CNE Cable	10mm²	1,90	2,34	50

House Service Connection Cable
Circular stranded hard drawn copper phase conductor, XLPE insulated with concentrically arranged identified bare earth conductors. Polyethylene sheathed 600/1000V house service connection cable. Nylon ripcord laid under sheath. Manufactured to SANS 1507 and NRS 062.

· Small overall diameter - concentric construction (SNE - Seperate Neutral Earth).
· Lower mass - due to smaller diameter - no steel wire armour
· Increased safety - reliable earthing
· Improved reliability - UV stable sheath and core insulation
· Tamper and vandal proof - unauthorised access to phase conductor inhibited by concentric layer.
· Easy strip with nylon ripcord


AIRDAC SNE Cables

Description	Cable size	Phase Conductor Resistance (Ohm/km) DC @ 20 °C	Earth Size (mm²)	Neutral Size (mm²)
10mm², AIRDAC SNE Cable	10mm²	1,90	7,5	10
16mm², AIRDAC SNE Cable	16mm²	1,20	10	16

House Service Connection Cable (with or without pilot cores)
Circular stranded hard drawn copper phase conductor, XLPE insulated with concentrically arranged identified neutral and bare earth conductors. Polyethylene sheathed 600/1000V service connection cable. Nylon ripcord laid under sheath. Manufactured to SANS 1507 and NRS 063.

· Small overall diameter - concentric construction (SNE - Separate Neutral Earth).
· Lower mass - due to smaller diameter - no steel wire armour
· Increased safety - reliable earthing
· Improved reliability - UV stable sheath and core insulation and water blocked
· Tamper and vandal proof - unauthorised access to phase conductor inhibited by concentric layer.
· Easy strip with nylon ripcord
