12 Cores Security Alarm Cables

SHG COMMUNICATION TECHNOLOGY (HANGZHOU) LTD.
  • Application：Local Communication Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：PVC
  • Type：Alarm Cable
  • Certification：CE, ISO, RoHS, CCC, UL, VDE, Reach
  • Security：Alarm Cable

Base Info

  • Model NO.：ALA-12C
  • Shield：Foil Shield , Unshield
  • Conductor：TCCA
  • Cable Care：2c,4c,6c,8c,10c,12c,14c,16c,20c
  • Transport Package：100m,200m,300m Reel , Coil
  • Specification：CE, UL, ETL, RoHS
  • Trademark：OEM
  • Origin：China
  • HS Code：854491100
  • Production Capacity：20000km Per Month

Description

Basic Info.

Model NO. ALA-12C Shield Foil Shield / Unshield Conductor TCCA Cable Care 2c,4c,6c,8c,10c,12c,14c,16c,20c Transport Package 100m/200m/300m Reel / Coil Specification CE, UL, ETL, RoHS Trademark OEM Origin China HS Code 854491100 Production Capacity 20000km Per Month

Product Description

SHG high quality 2/4/6/8/10/12 cores security alarm cables, apply for security & alarm system, high performance, quality warranty.
Certificates: ETL, CE, RoHS, ISO9001


1) Structure: Unshielded, shield
A> Conductor: TCCA (TC, BC, CCA are available)
B> Cable core: 2C, 4C, 6C, 8C, 10C, 12C, 14C, 16C, 20C
C> Insulation: PVC
D> rip cord: Yes
E> Shield: Al/foil
F> Drain wire: No
G> Jacket: PVC

2) Application:
A general purpose signal and alarm cable used for intruder alarm systems and access control applications. Wiring Burglar & Security alarms, public address systems, intercoms, telephone stations, speakers, instrumentation, control and other low voltage circuits that are power limited.

3) Standard packing:
100m/rolll, 100m/box; 100m/plastic spool; 300m pull box, 300m/wooden spool.


4) Workshop


5) Color Coding (see below)
ConductorsStrands  of  annealed  tinned  copper  wires
Conductor  insulationColour  coded  PVC,   flame  retardant
Core  colours
4  core
6  core
8  core
12  core		The  cores  are  colour  coded  as  follows:
Red,   blue,   yellow,   black
Red,   blue,   yellow,   black,   white,   green
Red,   blue,   yellow,   black,   white,   green,   orange,   brown
Red,   blue,   yellow,   black,   white,   green,   orange,   brown,   grey,   pink,   violet,   turquoise
ScreeningOptional.   Available  with  Aluminium  foil  screen
Outer  sheathPVC  with  nominal  radial  wall  thickness  0.5mm.   Colour  white.
Flame  retardant  to  IEC  60332-1
