• Model NO.：ALA-4C
• Cable Core：2c,4c,6c,8c,10c,12c,14c,16c,20c
• Conductor：CCA
• Jacket：PVC
• Transport Package：100m,200m,300m Reel , Coil
• Specification：CE, UL, ETL, RoHS
• Trademark：OEM
• Origin：China
• HS Code：85444911
• Production Capacity：20000km Per Month

Basic Info.

Model NO. ALA-4C Cable Core 2c,4c,6c,8c,10c,12c,14c,16c,20c Conductor CCA Jacket PVC Transport Package 100m/200m/300m Reel / Coil Specification CE, UL, ETL, RoHS Trademark OEM Origin China HS Code 85444911 Production Capacity 20000km Per Month

Product Description

High quality security alarm cable, appliy for security system, high performance, quality warranty.
Certificates: ETL, CE, RoHS, ISO9001

1) Structure: Unshielded, shield
A> Conductor: CCA (TC, BC, TCCA are available)
B> Cable core: 2C, 4C, 6C, 8C, 10C, 12C, 14C, 16C, 20C
C> Insulation: PVC
D> rip cord: Yes
E> Shield: Al/foil
F> Drain wire: No
G> Jacket: PVC
2) Application:
A general purpose signal and alarm cable used for intruder alarm systems and access control applications. Wiring Burglar & Security alarms, public address systems, intercoms, telephone stations, speakers, instrumentation, control and other low voltage circuits that are power limited.

3) Standard packing:
100m/rolll, 100m/box; 100m/plastic spool; 300m/wooden spool.

4) Color Coding

Conductors	Strands  of  annealed  tinned  copper  wires
Conductor  insulation	Colour  coded  PVC,   flame  retardant
Core  colours 4  core 6  core 8  core 12  core	The  cores  are  colour  coded  as  follows: Red,   blue,   yellow,   black Red,   blue,   yellow,   black,   white,   green Red,   blue,   yellow,   black,   white,   green,   orange,   brown Red,   blue,   yellow,   black,   white,   green,   orange,   brown,   grey,   pink,   violet,   turquoise
Screening	Optional.   Available  with  Aluminium  foil  screen
Outer  sheath	PVC  with  nominal  radial  wall  thickness  0.5mm.   Colour  white.  Flame  retardant  to  IEC  60332-1
