AAC Centipede Conductor
YIFANG ELECTRIC GROUP INC.- Application：Overhead
- Voltage：High Voltage Cable
- Current：DC & AC
- Insulation Material：Bare
- Sheath Material：None
- Material Shape：Round Wire
Base Info
- Model NO.：AAC Centipede CONDUCTOR
- Wire Core Material：Aluminum Wire
- Certification：ISO, CCC, CE, UL
- Model：AAC Centipede Conductor
- Brand：Yifangcable
- Code Name：AAC Centipede Conductor
- Material：Aluminum
- Strands：37
- Standard：BS 215 Part 1
- Exported Coutry：Zambia,etc
- Transport Package：Wooden Drum
- Specification：1.0m Drum
- Trademark：Yifang Cable
- Origin：China
- HS Code：7614900000
- Production Capacity：1000km,Month
Description
TECHNICAL DATA OF AAC Centipede CONDUCTOR NO DESCRIPTION UNIT DATA 1 Type/ code name -- AAC CENTIPEDE 2 Material -- Aluminum 3 Standards -- BS 215 4 Cross Section Area mm2 415.2 5 Conductor construction Wire No. No.s 37 Nominal wire dia. mm 3.78 6 Approx. Overall Diameter mm 26.46 7 Approx. Weight kg/km 1133 8 Max. D.C. Resistant 20ºC Ω/km 0.06944
