| Item | Prysmian Alternative TGSH Cable |
| Conductor | Copper, tinned, finely stranded |
| Insulation | Ozone, weather, heat and water resistant insulation compound, base SIR |
| Outer sheath | Special compound, base HEPR |
| Core Number | Multicores (As client's requirement) |
| Rated Voltage | 450/750V |
| Test Voltage | 2.5 kV |
| Temperature Range | Fix installation min. -50 °C
Flex. operation min. -50 °C |
| Color | Optional |
| Application | Rubber-sheathed cables TGSH are intended for connection of electrical equipment in hot water and for medium mechanical stresses. These cables are also suitable for use in industrial water, cooling water, surface water, rainwater, groundwater and seawater (salt water) up to 2000 m water depth. When corrosive water is involved, or water of some other special compositions must be investigated in each individual case. These cables can be used indoors, outdoors, in industrial and agricultural plant, but not in explosion-hazard areas. For protected, fixed installation within equipment, pipes or wells, as well as for motor connections, these cables may be operated with an AC voltage to 1000 V or a DC voltage to 750 V with respect to earth. The permissible AC voltage for motor tests is 3 kV for a maximum duration of 3 minutes. |
