Wdzan-Yjy-150 Cable Flame-Retardant Refractory Grade C LSZH 450/750V 0.6/1kv

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：Environment Protection Flame Retardant
  • Insulation Material：Calcined Synthethic Mica Refractory Belt
  • Material Shape：Round Wire

Base Info

  • Model NO.：WDZAN-YJY-150 Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemWDZAN-YJY-150 Cable Flame-retardant Refractory Grade C LSZH 450/750V 0.6/1KVConductorCopper wire bareInsulationHigh temperature resistance calcined synthethic mica refractory beltOuter sheathSpecial environmental protection flame-retardant sheathFire isolation layerHigh flame retardant coated alkali-free glass fiber woven tape with high resistance evironmental protection filling materialCore NumberMulticores (As client's requirement)Peak operating voltageUo/U 0.6/1 KV Test Voltage3500 VTemperatureOperating temperature: -40 ºC ~ + 90 ºCColorOptionalApplicationThe cable has been optimized for materials and structure tomaintain the integrity of the circuit for a period of time under fire conditions. At the same time it generates sight smoke when burned, non-toxic and non-corrosive-- good light transmission, and the cable itself is difficult to burn. Remove self-extinguishing under open flame conditions. Earn precious time for fire escape and effectively avoid loss of personal and property safety. Particularly suitable for theaters, conference halls, office buildings, airports, railway stations, subway stations, high-rise residences and other densely populated places or fire alarm, fire control, escape instruction systems. It has the characteristics of flame resistance and flame resistance, environmental protection, non-toxic, weather resistance, high and low temperature resistance, ozone resistance and radiation resistance.
