Low Temperature Resistance Anf8002 Cable High Speed Shield Towline Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：Special Thermoplastic Compound
  • Insulation Material：Special Elastomer Compound
  • Material Shape：Round Wire

Base Info

  • Model NO.：ANF8002 Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemLow Temperature Resistance ANF8002 Cable High Speed Shield Towline Cable ConductorSolid copper conductorInsulationSpecial thermoplastic polyestor elestomerSheildTinned copper wire braid, coverage rate 80%Outer SheathSpecial elastomer compoundCore NumberMulti-coresOperating VoltageUo/U: 300/300 V & 300/500 VTest voltage1500/2000 V Operating temperature rangeFlexible installations:-20ºC ~ +90ºC
Fixed installations:-40ºC ~ +90ºCColorOptionalApplicationThis cable is suitable for modern machining, machine too industry,robot and machinery production, construction machinery, heavy machinery factory,automobile manufacturing, automated warehouse and other occasions requiring high flexibility. With abrasion resistance, low temperature resistance, environmental protection and flame retardant. The mesh shielding layer composed of high-density and high-conductivity material can ensure that the cable still has strong anti-interference ability during the process of bending back and forth. It is particularly suitable for applications where frequent bending under high mechanical loads, flexibility at high speeds, and complex electric field interference.
