12/20 (24) Kv XLPE Insulated PVC Sheathed Unarmoured Power Cablesingle Core (Unarmoured)
YIFANG ELECTRIC GROUP INC.- Application：Construction, Underground
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：12,20kv cable BM41
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：YJV
- Brand：Yifang
- Option Conductor：Aluminum
- Transport Package：Wooden or Wooden-Steel Drum
- Specification：multicores
- Trademark：Yifang Cable
- Origin：Zhengzhou, China
- HS Code：8544601200
- Production Capacity：300km,Month
Description
Conductor
Conductor Insulation Insulation Copper Sheath Overall Cable Insulation Conductor
screen
thickness
screen
Conductor Insulation Insulation Copper Sheath Overall Cable Insulation Conductor
screen
thickness
screen
Insulation Copper Inner Armour Outer Overall Cable Insulation Conductor
thickness
Insulation Copper Inner Armour Outer Overall Cable Insulation
thickness
resistance at
15.6∑C (Min.)
( Mohm/km)
Size
(mm)
Shape
Outside
diameter
( mm )
50
70
95
120
150
C.C.
C.C.
C.C.
C.C.
C.C.
8.05
9.67
11.39
12.33
14.24
5.5
5.5
5.5
5.5
5.5
0.1
0.1
0.1
0.1
0.1
1.6
1.6
1.6
1.6
1.6
0.5
0.5
0.5
0.5
0.5
2.8
2.9
3.0
3.2
3.3
63
67
70
74
78
5370
6240
7340
8350
9530
2000
1800
1600
1500
1400
185
240
300
C.C.
C.C.
C.C.
15.98
18.32
20.65
5.5
5.5
5.5
0.1
0.1
0.1
1.8
1.8
1.8
0.5
0.5
0.8
3.4
3.5
3.7
82
87
94
11000
13100
16500
1300
1200
1100
