• Model NO.：LW-PMFC
• Core：Double Core
• Certification：RoHS, UL, CE, ISO9001, VDE, CCC
• Brand：OEM
• Sheath Material：PC
• Operating Wavelen：1550nm
• Grade：P,a
• Keywords：Pm Splitter Coupler
• Pdl (dB)：≤0.15
• Fiber Type：Pm Panda Fiber
• Wavelength：780nm 850nm
• Transport Package：Blister Box
• Specification：3x54mm
• Trademark：LIGHTWIT
• Origin：Shenzhen
• HS Code：85414000
• Production Capacity：2000

ItemParameterCenter Wavelength780, 850980, 10641310, 1480, 1550Bandwidth±15, ±40

Max.

Insertion

Loss @

Central

wavelength

CRPAPAPA50/50≤3.8≤4.0≤3.6≤3.8≤3.4≤3.630/70≤6.3/2.2≤6.5/2.4≤5.75/2.0≤6.1/2.1≤5.6/1.95≤5.75/2.120/80≤8.2/1.7≤8.5/1.9≤8.0/1.5≤8.2/1.7≤7.6/1.4≤8.0/1.510/90≤11.8/1.4≤12.0/1.6≤11.6/1.2≤11.8/1.4≤11/0.85≤11.6/1.05/95≤15/1.0≤15.2/1.2≤14.8/0.8≤15/1.0≤14.2/0.6≤14.8/0.83/97≤17.5/0.9≤17.7/1.0≤16.6/0.4≤17.2/0.6≤16.2/0.4≤16.7/0.52/98≤19.0/0.8≤19.2/1.0≤18.4/0.4≤18.9/0.5≤18.0/0.4≤18.5/0.51/99≤22.5/0.7≤22.8/0.9≤22/0.4≤22.5/0.6≤21.5/0.3≤22/0.4ERCR>5%2018201820185%≥CR>1%181618161816CR≤1%Out of concernSteel Tube Size3*54Return loss≥50Directivity≥50Fiber typePanda PM fiberPower handling≤500Operating Environment Temperature-5-+70Storage Temperature-40-+85

* IL is 0.3dB(1310~1550) or 0.5dB(980~1060) or 0.8dB(780~850) higher for devices with connectors.

** RL is 5 dB lower, ER is 2 dB lower for each connector added. Connector key is aligned to slow axis.
