245 IEC 03 (yg) Fiberglass Braided Silicone Rubber Wire
Jiangyin Yuanda Electrical Material Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Heating, Underground
- Conductor Material：Tinned Copper
- Insulation Material：Silicone Rubber
- Certification：ISO9001, UL, CCC, RoHS, VDE
Base Info
- Model NO.：245 iec 03(yg)
- Spec AWG：30-16
- Color：as The Customer Requires
- MOQ：5000 Meters
- Delivery：Within 25 Days
- Certificate：E216252 CSA229260
- Transport Package：Pallet,Carton,Tray,Reel
- Specification：ISO9001, UL, CCC, RoHS, VDE
- Trademark：Yuanda
- Origin：Wuxi, China
- Production Capacity：1000km,Day
Description
| Conductor | Instulation | ||||||
| Nominal section mm2 | Conductor construction No./mm | Diameter mm | normal thickness mm | Fiberglass thickness mm | Nominal outer diameter mm | Max outer diameter (mm) | |
| 0.5 | 20/0.18 | 0.94 | 0.6 | 0.15 | 2.5 | 2.7 | 40.1 |
| 0.75 | 42/0.15 | 1.13 | 0.6 | 0.15 | 2.7 | 2.9 | 26.7 |
| 1 | 32/0.20 | 1.31 | 0.6 | 0.15 | 2.9 | 3.1 | 20.0 |
| 1.5 | 30/0.25 | 1.58 | 0.7 | 0.18 | 3.4 | 3.6 | 13.7 |
| 2.5 | 49/0.25 | 2.06 | 0.8 | 0.18 | 4.0 | 4.2 | 8.21 |
| 4 | 56/0.30 | 2.6 | 0.8 | 0.2 | 4.6 | 4.9 | 5.09 |
| 6 | 84/0.30 | 3.6 | 0.8 | 0.2 | 5.6 | 5.9 | 3.39 |
| 10 | 84/0.40 | 4.6 | 1 | 0.25 | 7.1 | 7.6 | 1.95 |
| 16 | 126/0.40 | 5.5 | 1 | 0.25 | 8.0 | 8.7 | 1.24 |
