Low Smoke Halogen Free Armoured Cable Rz1mz1-K (AS) Cable 0, 6/1kv

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：LSZH
  • Insulation Material：XLPE
  • Material Shape：Round Wire

Base Info

  • Model NO.：RZ1MZ1-K (AS) Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemRZ1MZ1-K (AS) Cable ConductorElectrolytic copper, class 5 (flexible)InsulationCross-linked Polyethylene (XLPE)Inner SheathThermoplastic polyolefin sheathScreeningBraided annealed red copperOuter SheathLow Smoke halogen free (LSHF) polyolefinCore NumberMulti-coresMaximum conductor temperaturesNormal operation 90°C. Short circuit (5sec) 250°CTesting voltage3.500 V C.A.Nominal VoltageUo/U 600/1000 VColorOptionalApplicationThis cable is highly recommended in hazardous areas with explosive gas atmospheres (ATEX) or with risk of fire (Petrochemical plants, gas stations, flammable product stores, etc.) and in general, where the cable is subject to risk of mechanical aggression.
