Cable Manufacturing CE PVC Nycwy Power Cable 2.5mm2 up to 150mm2

Shanghai Aein Wire & Cable Co., Ltd.

Type：Insulated
Conductor Type：Stranded
Application：Installation
Conductor Material：Copper
Sheath Material：PVC
Insulation Material：PVC

Base Info

Model NO.：NYCWY
Material Shape：Round Wire
Range of Application：Weather Resistant
Certification：ISO9001, CE, UL, RoHS
Brand：Aein
Transport Package：Optional
Specification：Multicore
Trademark：AEIN
Origin：Shanghai
HS Code：8544492100

Description

ItemNYCWY Power CableConductorBare Copper (as client's required)InsulationSpecial PVC (as client's required)Outer SheathSpecial PVC (as client's required)Specifications2.5mm2 up to 150mm2Nominal VoltageUo/U: 0.6/1KVTest Voltage4000VTemperature RatingDuring installation -5°C to +70ºC Fixed Installation: -20°C to +70°CMinimum Bending Radius12 x cable diameterColorOptionalCertificationCECharacteristicWeather resistant
UV resistant
Flame-retardant
Environmental protectionApplicationWidely used in industrial systems, power stations, housejunction boxes and street lighting. Can be used in applications that require increased power and mechanical protection. Can be installed in the open air, underground, concrete, indoor and cable ducts. The concentric conductor layer can be used as a ground conductor or a cable shield. Weather-resistant and can be used outdoors.
