75 Ohm French Standard TV Trunking Cables 11vatc/Patc for CATV
Hangzhou Hongfeng Cable Co., Ltd.- Application：Local Communication Cable, Fiber Optic Cable, Long Distance Symmetric Cable, Submarine Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：11vatc,Patc
- Material Shape：Flat Wire
- Conductor Type：Solid
Base Info
- Model NO.：11vatc,patc
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, UL
- Model：11vatc,Patc
- Brand：Hf
- Insulation：PVC
- Jacket：PVC
- Conductor：Bc
- Transport Package：1)100m,Coil, 6 Coils,CTN 2)305m,Wooden Drum
- Specification：2
- Origin：Lin an
- HS Code：8518290000
- Production Capacity：300km,Day
Description
1000-3000 MHz≥20dB Frequency(MHz) Attenuation(dB /100m) Attenuation(dB /100ft) 50 2.70 0.89 100 3.80 1.25 200 5.40 1.77 400 7.70 2.52 800 11.00 3.61 950 12.10 3.97 1350 14.60 4.79 1750 16.70 5.48 2150 18.70 6.13 3000 22.30 7.31
