UTP FTP Cat5e Cat6e
Hangzhou Hongfeng Cable Co., Ltd.- Application：Local Communication Cable, Fiber Optic Cable, Long Distance Symmetric Cable, Submarine Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Cat 5
- Material Shape：Flat Wire
- Conductor Type：Solid
Base Info
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, UL
- Model：2
- Brand：Hf
- Insulation：PVC
- Jacket：PVC
- Conductor：Bc
- Transport Package：1)100m,Coil, 6 Coils,CTN 2)305m,Wooden Drum
- Specification：2
- Origin：Lin an
- HS Code：8518290000
- Production Capacity：300km,Day
Description
Basic Info.
Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS, UL Model 2 Brand Hf Insulation PVC Jacket PVC Conductor Bc Transport Package 1)100m/Coil, 6 Coils/CTN 2)305m/Wooden Drum Specification 2 Origin Lin an HS Code 8518290000 Production Capacity 300km/DayProduct Description
| Structure | Material | Specification |
| Core No. | - | 4 |
| Conductor | BC | 23AWG |
| Insulation | PE | 1.04mm Thickness |
| 1st Shield | Selectable | - |
| 2nd Shield | Selectable | - |
| Drain Wire | - | - |
| Jacket | PVC | 5.7mm Thicknes |
| Cable Type | Structure(mm) | Insulation thickness(mm) | Approx overall dia.(mm) |
| FTP CAT5E | 4x0.48 | 0.92 | 6.4 |
| FTP CAT5E | 4x0.50 | 0.94 | 6.5 |
| FTP CAT5E | 4x0.52 | 0.96 | 6.5 |
| UTP CAT5E | 4x0.48 | 0.9 | 5.2 |
| UTP CAT5E | 4x0.50 | 0.91 | 5.3 |
| UTP CAT5E | 4x0.52 | 0.93 | 5.3 |
| FTP CAT6 | 4x0.50 | 0.98 | 7.3 |
| FTP CAT6 | 4x0.55 | 1.03 | 7.4 |
| FTP CAT6 | 4x0.57 | 1.05 | 7.4 |
| UTP CAT6 | 4x0.50 | 0.96 | 6.3 |
| UTP CAT6 | 4x0.55 | 1.01 | 6.4 |
| UTP CAT6 | 4x0.57 | 1.03 | 6.4 |
