4 Core Fire Resistance Security Alarm Cable
Hangzhou Hongfeng Cable Co., Ltd.- Application：Local Communication Cable
- Conductor Material：Copper
- Cover Material：PVC
- Type：Alarm Cable
- Material Shape：Round Wire
- Conductor Type：Stranded
Base Info
- Model NO.：Alarm Cable
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, CCC
- Model：MHYV-xx
- Brand：Hongfeng
- HS Code：8544200000
- Production Capacity：30, 000piece,Year
Description
Basic Info.
Model NO. Alarm Cable Wire Core Material Bare Copper Wire Certification CE, ISO, RoHS, CCC Model MHYV-xx Brand Hongfeng HS Code 8544200000 Production Capacity 30, 000piece/YearProduct Description
Basic Info
Model NO.: Alarm Cable
Wire Core Material: Bare Copper Wire
Certification: CE, ISO, RoHS
Model: Rvv
Brand: Fuu
Transport Package: 100m
Specification: 12awg Conductor
Origin: China
HS Code: 8544200000
4 Core Fire Resistance Security Alarm Cable
Alarm Cable/Control Cable
- Conductor Material: CU/CCA
- Insulation Material: PVC
- Insulation Diameter: 1mm/1.5mm
- Drian Wire Material: N/A
- Jacket Material: PVC
- Signal Shield: Al/Polyester Foil; Coverage>100%.
- Double Fully Shield: Al/Polyester Foil + Tinned Copper Braid
Fire Cable/Fire Alarm Cable
- Conductor Material: CU
- Insulation Material: PVC
- Insulation Diameter: 1.8mm/2.15mm/2.40mm/2.80mm
- Drian Wire Material: 0.5mm CU
- Jacket Material: PVC
- Signal Shield: Al/Polyester Foil; Coverage>100%
Alarm Cable/Control Cable
| Cable Size | Specification | Overall Diameter |
| 2x0.22mm² | 2x7/0.20 | 3.0mm |
| 4x0.22mm² | 4x7/0.20 | 3.5mm |
| 6x0.22mm² | 6x7/0.20 | 4.1mm |
| 8x0.22mm² | 8x7/0.20 | 4.5mm |
| 10x0.22mm² | 10x7/0.20 | 5.2mm |
| 12x0.22mm² | 12x7/0.20 | 5.6mm |
| 14x0.22mm² | 14x7/0.20 | 5.8mm |
| 20x0.22mm² | 20x7/0.20 | 6.8mm |
| 2x0.50mm² | 2x16/0.20 | 4.5mm |
| 4x0.50mm² | 4x16/0.20 | 5.2mm |
| 6x0.50mm² | 6x16/0.20 | 6.0mm |
| 8x0.50mm² | 8x16/0.20 | 6.8mm |
| 10x0.50mm² | 10x16/0.20 | 7.6mm |
| 12x0.50mm² | 12x16/0.20 | 8.0mm |
Fire Cable/Fire Alarm Cable
| Cable Size | Specification | Overall Diameter |
| 2x0.5mm² | 2x0.8mm | 4.80mm |
| 2x2x0.5mm² | 4x0.8mm | 6.00mm |
| 2x1.0mm² | 2x1.15mm | 5.30mm |
| 2x2x1.0mm² | 4x1.15mm | 6.60mm |
| 2x1.5mm² | 2x1.40mm | 5.90mm |
| 2x2x1.5mm² | 4x1.40mm | 7.20mm |
| 2x2.5mm² | 2x1.80mm | 6.80mm |
| 2x2x2.5mm² | 4x1.80mm | 8.00mm |
Application:
For internal wiring in class 2 circuits of electronic equipment or TV game data transmission.
Packing:
1)Packing Lengths: 100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll.
2) Inner packing:Roll, Wooden reel, plastic reel, and paper reel.
3) Outer packing: Carton box, pull out box, pallet available.
4) Other packing available according to client's request.
