CAT6 Bulk Ethernet/LAN Cable 23AWG CCA 550MHz 1000 Feet Black
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, LAN Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：PVC
- Type：Cat 6
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：cat6
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS
- Model：Cat5
- Brand：Fuu
- Transport Package：305m
- Specification：0.57mm conductor
- Origin：China
- HS Code：8544200000
- Production Capacity：5000km,Month
Description
Construction
Conductor
Dimension
Core Dimension
No. of Pair
Shielding
Nom O.D.
UTP
0.57
1.02
4
-
6.0
FTP
0.57
1.00
4
Al foil
6.3
S-FTP
0.57
1.00
4
Al foil+Cu braiding
6.6
Conductor: 26AWG Solid BC (the exact sizes are all according to you request)
Insulation: Solid polyolefin
Cabling: 4 twisted pairs cabled around a cross shaped central filler into the cable core.
Shielding: Aluminum Mylar Spirally Wrapped(FTP)
Braiding: TC/Aluminum Magnesium alloy Solid(SFTP)
Jacket: PVC/FR-PVC/LSOH
Production Standard
ISO/IEC 11801:2002(Categoy5e)
IEC 61156-5:2002(Category5e)
IEC 61156-7:2003
UL CM
UL CMP and CSA FT6
UL CMR and CSA FT4
LSOH: IEC 60332-1, IEC 60332-3
IEC60754-2, IEC 61034
Compliance with
² ISO/IEC 11801
² TIA/EIA-568-8.2
² IEC-60332-1
² UL 444 (CM/CMR/CMP grade)
² RoHS
Application
100 Base-T4
100 Base-TX
100VG-AnyLAN
1000 Base-T(Gigabit Ethernet)
155 Mbps ATM
622 Mbps ATM
Product Describtion
Rated temperature 60°C, 75°C
Reference standard UL444, TIA/EIA 568B
Bare solid or stranded copper conductor
Colour-coded PE insulaation
Rip cord (optional)
Lead free PVC or LSOH jacket
Reelex Pull-out Box Packing
