Copper Conductor XLPE Insulated Armored Electrical Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Underground, Industrial
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：N2XY YJV VV R2V
- Certification：ISO, CCC, CE
- Model：YJV
- Brand：Hongda
- Color：as Customer Requirement
- Transport Package：Steel-Wooden Drum,Wooden Drum
- Specification：As customer requirement
- Trademark：HONGDA
- Origin：China
- Production Capacity：2000m,Week
Description
For laying indoors, in tunnel, cable trench, well or direct in ground, able to bear external mechanical forces and certain pulling forceYJV33 (CU/XLPE/SWA/PE) YJLV33 (AL/XLPE/SWA/PE) Cu conductor(Al conductor)XLPE insulated steel-wire armored PE sheathed power cable YJV72 (CU/XLPE/AWA/PVC) YJLV72 (AL/XLPE/AWA/PVC) Cu conductor(Al conductor)XLPE insulated aluminium-wire armored PE sheathed power cable
5 Construction
5.1 XLPE insulated Power Cables for rated voltages up to and including 0.6/1kV
Conductor shaped: RE=circular solid, CC=compacted circular stranded, SM=sector shaped stranded
Conductors: Plain circular, compacted or shaped stranded copper or aluminium conductor
Insulation: XLPE (cross-linked polyethylene) rated at 90°C
Color identification
1 Core : Red or Black, 2 Cores : Red, Black, 3 Cores: Red, Yellow, Blue
4 Cores: Red, Yellow, Blue, Black, 5 Cores: Red, Yellow, Blue, Black, Green
Above 5 Cores: Black Cores with White numerals
*The above identifying can be changed as user requirement
Assembly /Inner Sheath :Two, Three or Four insulated conductors are laid-up together with non-hygroscopic fillers and the assembly is bedded with an extruded layer of PVC. In case of non-armoured cables, this layer may be omitted
Armour: Aluminum/Galvanized Steel Wires, single core cables shall be Aluminium wire armour, Aluminum/Steel Tapes applied helically over the bedding of multi-core cables as per IEC 60502.
Outer Sheath:Outer sheath shall be of Extruded PVC Type ST2 as per IEC 60502-1 or Type 9 as BS 6346/5467.Special type of PVC sheathing material such as Fire Retardant PVC, Anti-Termite PVC, Anti-Rodent PVC, Sunlight resistant PVC, Oil Resistant PVC are available on special request. Also, special sheathing materials such as LLDPE, MDPE, HDPE, LSZH, and CPE are available on request.
Fire Performance of Cable Sheaths
Cables can be supplied with special flame retardant PVC outer sheath to comply With the flame test requirements of IEC 60332-3-22, IEC 60332-3-23 and IEC 60332-3-24, we can also supply cables with Low Smoke Halogen Free (LSHF) material according to IEC 60502-1, BS 7211, BS 6724 or other equivalent standards.
