• Model NO.：LT-HFRPL
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, RoHS
• Brand：Lt
• Transport Package：2-5kg,Cone
• Specification：1-10mm
• Trademark：longtai
• Origin：China

Basic Info.

Model NO. LT-HFRPL Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, RoHS Brand Lt Transport Package 2-5kg/Cone Specification 1-10mm Trademark longtai Origin China

Product Description

LOI > 45 high fire retardant spun polyester yarn for cable filling
(Oxygen Index >=45)
Jiangxi Longtai New Material Co., Ltd developed a new advanced product :  Nano High Fire Retardant Halogen Free Cable filler . It's compounded by special high-tech processes , with the feature of high fire retardant , Oxygen Index can reach to 45, refractory grade cable filler.

You will like use it,becaue it have so many good advantages:


1. High flexible,make cable wires round.
2. High fire retardant,high temperature resistant.
3. No dripping when using.
4. Low smoke halogen free,passed by testing of Rohs,REACH.
5. No halogen,asbestos and glass fiber.
6. Light weight, cost-effective.

Application: All kinds of flame retardant & high temperature resistant cables;
such as flame retardatnt power cables, flame retardant mine cables, flame retardant marine cables, flame retardant silicone rubber cables…
This product has passed the testing by the National Wire & Cable Testing Center, corresponding to the requirements of the environmental friendly fire retardant cables.

Specification data sheet:

Type	Weight (g/m)	Tensile Strength(N)	Elongation(%)	Oxygen Index(%)	Long Term Stability (ºC)	Melting Point(ºC)
2mm	2.2±0.2	≥70	≥5	≥40	>250	>200
3mm	4±0.4	≥100	≥5	≥40	>250	>200
4mm	7±0.7	≥150	≥5	≥40	>250	>200
5mm	9±0.8	≥200	≥5	≥40	>250	>200
6mm	12±1.0	≥250	≥5	≥40	>250	>200

Compare with other flame retardant filler materials:


Item	Diameter mm	Density g/m	OI %	Flexible	Eco-friendly	High temperature resistant
High temperature flame retardant filler yarn	2	2.2	>45	High flexible	Yes,halogen free	Yes,and no dripping
Fiberglass rope	2	4	>50	hard	no	yes
Asbestos rope	2	4	>80	commonly	no	yes
FR PP filler yarn	2	1.8	>28	High flexible	no	no
Ceramic polyolefin filling rope	2	4	>40	commonly	yes	yes
