Loi > 45 High Fire Retardant Spun Polyester Yarn for Cable Filling
Jiangxi Longtai New Material Co., Ltd.- Type:Insulated
- Conductor Type:Stranded
- Application:Heating, Underground
- Conductor Material:Aluminum
- Sheath Material:PVC
- Insulation Material:PVC
Base Info
- Model NO.:LT-HFRPL
- Material Shape:Round Wire
- Range of Application:Flame Retardant
- Certification:ISO9001, RoHS
- Brand:Lt
- Transport Package:2-5kg,Cone
- Specification:1-10mm
- Trademark:longtai
- Origin:China
Description
Basic Info.
Model NO. LT-HFRPL Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, RoHS Brand Lt Transport Package 2-5kg/Cone Specification 1-10mm Trademark longtai Origin ChinaProduct Description
LOI > 45 high fire retardant spun polyester yarn for cable filling(Oxygen Index >=45)
Jiangxi Longtai New Material Co., Ltd developed a new advanced product : Nano High Fire Retardant Halogen Free Cable filler . It's compounded by special high-tech processes , with the feature of high fire retardant , Oxygen Index can reach to 45, refractory grade cable filler.
You will like use it,becaue it have so many good advantages:
- High flexible,make cable wires round.
- High fire retardant,high temperature resistant.
- No dripping when using.
- Low smoke halogen free,passed by testing of Rohs,REACH.
- No halogen,asbestos and glass fiber.
- Light weight, cost-effective.
such as flame retardatnt power cables, flame retardant mine cables, flame retardant marine cables, flame retardant silicone rubber cables…
This product has passed the testing by the National Wire & Cable Testing Center, corresponding to the requirements of the environmental friendly fire retardant cables.
Specification data sheet:
Type | Weight (g/m) | Tensile Strength(N) | Elongation(%) | Oxygen Index(%) | Long Term Stability (ºC) | Melting Point(ºC) |
2mm | 2.2±0.2 | ≥70 | ≥5 | ≥40 | >250 | >200 |
3mm | 4±0.4 | ≥100 | ≥5 | ≥40 | >250 | >200 |
4mm | 7±0.7 | ≥150 | ≥5 | ≥40 | >250 | >200 |
5mm | 9±0.8 | ≥200 | ≥5 | ≥40 | >250 | >200 |
6mm | 12±1.0 | ≥250 | ≥5 | ≥40 | >250 | >200 |
Compare with other flame retardant filler materials:
Item | Diameter mm | Density g/m | OI % | Flexible | Eco-friendly | High temperature resistant |
High temperature flame retardant filler yarn | 2 | 2.2 | >45 | High flexible | Yes,halogen free | Yes,and no dripping |
Fiberglass rope | 2 | 4 | >50 | hard | no | yes |
Asbestos rope | 2 | 4 | >80 | commonly | no | yes |
FR PP filler yarn | 2 | 1.8 | >28 | High flexible | no | no |
Ceramic polyolefin filling rope | 2 | 4 | >40 | commonly | yes | yes |
