Helukable Alternative Data Cable for Interference-Free Transmission of Data and Signals

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PE
  • Material Shape：Round Wire

Base Info

  • Model NO.：Li2YCYv Cable
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemData Cable  For Interference-free Transmission Of Data And Signals ConductorCopper wire bare, strandedInsulationPEWrappingFoilScreenBraided screen of tinned copper wires, approx. coverage 85%Outer sheathPVCOperating Voltage250 V (not for high power current installation purposes)Test Voltage2 kVTemperature RangeFlexible -5°C to +70°C
Fixed -30°C to +80°CMinimum Bending RadiusFlexible 12x Outer-Ø
Fixed 7.5x Outer-ØColorOptionalApplicationPE-insulated data cable with twisted pairs, for interference-free transmission of data and signals over longer distances. The twisted-pair lay-up prevents electrical unbalances within the cable and this thus effectively suppresses cross-talking effects. The high transmission rates are particularly suitable for RS 422 and RS 485 interfaces; suitable for fixed installations in dry, damp and wet rooms, as well as outdoors and direct burial. EMC= Electromagnetic Compatibility; in order to optimise EMC properties, we recommend a double-sided and all-round large contact area of the copper braiding.
