UL Style 2464 Data Cable PVC Insulated and Sheathed Low Voltage

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：UL2464
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemUL Style 2464 Data Cable PVC Insulated and Sheathed Low VoltageConductorCopper wire tinned, finely stranded, AWG sizesInsulationSemirigid PVCWrappingFoilScreenBraided screen of tinned copper wires, approx. coverage 85%Outer sheathPVCOperating Voltage300 V (not for high power current installation purposes)Test Voltage1.5 kVTemperature RangeFlexible -10°C to +80°C
Fixed -40°C to +80°CMinimum Bending RadiusFlexible 15x Outer-Ø
Fixed 7.5x Outer-ØColorOptionalCertificationULApplicationUL approved, screened, twisted pair data cable for use as a signal and measuring cable in machine tools, assembly lines, conveyor belts, plant construction, air conditioning devices, metallurgical plants, steel mills. EMC= Electromagnetic Compatibility; in order to optimise EMC properties, we recommend a double-sided and all-round large contact area of the copper braiding.
