• Model NO.：PVC insulated yellow-green earth cable 10mm2 16mm2
• Certificate：ISO;Ce;UL;Kema
• Transport Package：Wood Packing by Sea
• Specification：1000meter per drum
• Trademark：Yifang
• Origin：China
• HS Code：8544601200
• Production Capacity：300km Per Month

Basic Info.

Model NO. PVC insulated yellow-green earth cable 10mm2 16mm2 Certificate ISO;Ce;UL;Kema Transport Package Wood Packing by Sea Specification 1000meter per drum Trademark Yifang Origin China HS Code 8544601200 Production Capacity 300km Per Month

Product Description

APPLICATION:

For use on single phase and three phase dry fixed wiring systems operating at not more than 450V  between phase to earth or 750 V phase to phase at maximum conductor temperatures of 70 °C for continuous normal operation and 160 °C for short circuit. Suitable only when enclosed in a metallic or non-metallic conduit, ducting or trunking (see Methods of Installation overleaf). Also for installation inside appliances, switchgear and control gear and in or on lighting fittings.

STANDARDS:

Conforms to IEC 60227-3 for type 227 IEC 01, HD 21.3 S3:1995, BS6004 and DIN VDE 0281-3

CONSTRUCTION:

Copper single wire or stranded compacted circular conductor; extruded polyvinyl chloride (PVC) colored insulation applied

Annealed copper single wire or stranded compacted circular conductor according to IEC 60228 class 1 or class 2.

INSULATION

- Directly over the conductor shall be applied a homogeneous wall of PVC insulation. The average thickness shall be not less than the given in the attached table.

- Properties of the insulation shall be in accordance with any of the following standards: IEC 60227-3, HD 21.3 S3:1995, BS6004, DIN VDE 0281-3 or Israeli Standards 473.1.

CHARACTERISTICS

Mechanical resistance, to impacts Low Flexibility Semi-flexible

Temperature range -15 to +70 °C

Flame retardant IEC 60332-1

Weather resistance Good

Chemical resistance Accidental

Water proof Accidental
