Crane Cable Nshtouk-Z-742 Flexible Drum Reeling Cable 0, 6/1 Kv

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Crane Facilities
  • Conductor Material：Copper
  • Sheath Material：Neoprene
  • Insulation Material：Rubber

Base Info

  • Model NO.：Crane Cable NSHTOUK-Z-742
  • Material Shape：Round Wire
  • Range of Application：Crane Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemCrane Cable NSHTOUK-Z-742ConductorCopper wire bareInsulationRubberOuter SheathNeopreneVoltage RatingU0/U: 0,6/1 kVTemperaturefixed installation: -45°C to +70°C
flexible application: -25°C to +70°CColorOptionalApplicationThe crane cable NSHTÖUK-Z-742 is suitable where there are heavy mechanical tasks such as frequent winding and unwinding with torsional strain. This occurs especially in transport, conveyor and hoist systems. The neoprene outer sheath makes the cable resistant to ozone and UV radiation as well as to oil, acid, fat and solvents. The cable may be used in dry, damp and wet rooms as well as outdoors.
