• Model NO.：Shielded Alarm Cable
• Material Shape：Round Wire
• Range of Application：Flame Retardant
• Certification：ISO9001, CE, RoHS, CPR,SGS,ETL
• Brand：Risun or OEM
• Shield：Pet Foil,Al Foil
• Color：According to Customer
• Frame Retardant Level：Normal,Cm,Cmr
• Transport Package：100, 200, 500m,Roll or Wooden Reel
• Specification：ETL, CE, RoHS, SG, ISO9001
• Trademark：Risun or OEM
• Origin：Hangzhou, China(Mainland)
• HS Code：8544491100

Basic Info.

Model NO. Shielded Alarm Cable Material Shape Round Wire Range of Application Flame Retardant Certification ISO9001, CE, RoHS, CPR/SGS/ETL Brand Risun or OEM Shield Pet Foil/Al Foil Color According to Customer Frame Retardant Level Normal/Cm/Cmr Transport Package 100, 200, 500m/Roll or Wooden Reel Specification ETL, CE, RoHS, SG, ISO9001 Trademark Risun or OEM Origin Hangzhou, China(Mainland) HS Code 8544491100

Product Description

Factory sale Multi Cores Shielded Security Alarm Cable.


Flexible cable used for the wiring of burglar  Alarm and other low voltage circuits. Suitable application Multi core Audio, Control, Fire Alarm and Instrumentation cable for  Industrial, Data, Interconnect and Analogue Audio used.

Features:

Unshield alarm cable:
1. Conductor: 0.22mm² TC/BC/CCA, can 2-40 cores.
2. Frame Retardant PVC insulation
3. Ripcord
4. Frame Retardant PVC jacket.

Shielded alarm cable:
1. Conductor: 0.22mm² TC/BC/CCA, can 2-40 cores.
2. Frame Retardant PVC insulation
3. Pet Foil/Aluminum foil
4. Drain wire
5. Ripcord
6. Frame Retardant PVC jacket.

Packing:
100m/roll, 200m/roll, 305m/roll, 100yard/roll, 200yard/roll, 300yard/roll
Other lengths available according to client's request;

Usage: Securitity alarm
Certificate: CE, RoHS, ETL.


SERIAL No.	SECTION	SPEICIFICATION	OVERALL DIAM. mm	WEIGHT (KG/KM)
RS-AL01	2*0.22mm2	2*7/0.20	3	11
RS-AL02	4*0.22mm2	4*7/0.20	3.5	18
RS-AL03	6*0.22mm2	6*7/0.20	4.1	25
RS-AL04	8*0.22mm2	8*7/0.20	4.5	32
RS-AL05	10*0.22mm2	10*7/0.20	5.2	39
RS-AL06	12*0.22mm2	12*7/0.20	5.4	46
RS-AL07	14*0.22mm2	14*7/0.20	5.8	54
RS-AL08	20*0.22mm2	20*7/0.20	6.8	76
RS-AL09	30*0.22mm2	30*7/0.20	8.4	114
RS-AL10	40*0.22mm2	40*7/0.20	10	148

The specification, packing, pringting brand all according to customer.
