JG Silicone Insulated Cable High Temperature Resistant Motor Winding Lead Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type:Insulated
- Conductor Type:Stranded
- Application:Non Detachable Flexible Cable
- Conductor Material:Copper
- Sheath Material:Rubber
- Insulation Material:Rubber
Base Info
- Model NO.:JG
- Material Shape:Round Wire
- Range of Application:Non Detachable Flexible Cable
- Certification:ISO9001, CE, UL, CCC, RoHS, VDE
- Brand:Feiya
- OEM:Yes
- Transport Package:Wooden Box Packing or Pallet Shipping Containers
- Specification:copper
- Trademark:Feiya
- Origin:China
- HS Code:854449210
- Production Capacity:80000 Meter,Meters Per Month
Description
Model
name
Maximum conductor temperature
JV
PVC insulated motor winding connection cable (wire)
+70ºC
JF
Nitrile PVC compound insulated motor winding connection cable (wire)
+70ºC
JE
EPR insulated motor winding connection cable (wire)
+90ºC
JEH
Ethylene-propylene rubber insulated the chlorosulfonated polyethylene sheath motor the rewinder winding connection cable (wire)
+90ºC
JEM
Ethylene propylene rubber insulated the chloro ether sheath motor winding connection cable (wire)
+90ºC
JH
Chlorosulfonated polyethylene insulated motor winding connection cable (wire)
+90ºC
JG
Silicone rubber insulated motor winding connection cable (wire)
+180ºC
conductor
construction
No.*mminsulation thickness
mm OD
MM MAX. OD
MM Packing
m/roll 500v 1000v 500V 1000V 500v 1000v 0.12 7/0.15 0.6 0.8 1.65 2.05 1.9 2.36 300 0.2 12/0.15 0.6 0.8 1.80 2.20 2.07 2.53 300 0.3 16/0.15 0.6 0.8 1.90 2.30 2.19 2.65 300 0.4 23/0.15 0.8 1.0 2.40 2.80 2.76 3.22 300 0.5 16/0.2 0.8 1.0 2.53 2.93 2.91 3.37 300 0.75 24/0.2 1.0 1.2 3.14 3.54 3.60 4.07 200 1.0 32/0.2 1.0 1.2 3.32 3.72 3.80 4.28 200 1.5 30/0.25 1.0 1.2 3.60 4.00 4.14 4.60 200 2.0 40/0.25 1.0 1.2 3.84 4.24 4.42 4.87 200 2.5 49/0.25 1.0 1.2 4.00 4.40 4.60 5.06 200 4.0 56/0.3 1.2 1.4 5.00 5.40 5.74 6.20 200 6.0 84/0.3 1.2 1.4 6.00 6.40 6.90 7.36 200 10.0 84/0.4 1.4 1.6 7.40 7.80 8.50 8.97 100 16.0 126/0.4 1.4 1.6 8.50 8.90 9.78 10.23 100 25.0 196/0.4 1.6 1.8 10.30 10.7 11.84 12.31 100 35.0 276/0.4 1.8 2.0 12.10 12.5 13.92 14.38 50 50.0 396/0.4 2.0 2.2 14.30 14.7 16.44 16.91 50 70.0 360/0.5 2.0 2.2 16.40 16.8 18.86 19.32 50 95.0 475/0.5 2.2 2.4 18.90 19.3 21.74 22.2 50 120.0 608/0.5 2.2 2.4 20.40 20.8 23.46 23.92 50
mm
MM
MM
m/roll
FAQ
Q1:Are you a trading company or manufacturer?
A1: Tianjin Feiya wire & Cable CO., LTD. is a professional manufacturer.
Q2: What kinds of products does Tianjin Feiya wire & Cable CO., LTD. manufacture?
A2: Our products mainly cover low, medium and high voltage (KV) crosslinked polyethylene insulated power cable,PVC insulated power cable, PVC insulated wire (construction cable), control cable, signal cable, rubber cable,coal mine cable, welding cable, ship cable and other related customized cables. These cables are used in Power metallurgy, Oil&Chemical Industry, Nation Defense Power Station, Mine, Port and Architectural Engineering, andother fields.
Q3:Which standards do you comply with when you produce the electrical wires and cables ?
A3: We have passed ISO9001:2000 and ISO140001:2004. All products conform to GB, IEC, BS, ASTM, VDE JB and UL standards. Besides, we have the ability to design and produce various wires and cables, and customize them for you according to the special requirements of customers (providing OEM services).
Q4: What is your MOQ?
A4: It`s base on the cable type or wire type. Please contact Calder. He will let you know.
Q5:How much the Courier freight will be for the samples?
A5:Courier freight depends on the quantity,weight and carton size and your area.
