Nhxmh, Electric Wire, 300/500 V, Cu/XLPE/Lszh (LSOH) Cable (VDE 0250-214)
Jiangsu Boan Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Underground
- Conductor Material：Copper
- Sheath Material：PVC
- Insulation Material：XLPE
Base Info
- Model NO.：NHXMH
- Material Shape：Round Wire
- Range of Application：LSOH
- Certification：ISO9001, CE, CCC
- Brand：Boan
- Rated Voltage：300,500 V
- Number of Cores：1-7
- Class of Conductor：1,2
- Size：1.5-16 Mm2
- Transport Package：Heated Steel-Wooden Drum,Wooden Drum
- Specification：SGS
- Trademark：DingAn or OEM
- Origin：Jiangsu Yixing, China
- HS Code：8544492100
- Production Capacity：38000 Km,Year
Description
Basic Info.
Model NO. NHXMH Material Shape Round Wire Range of Application LSOH Certification ISO9001, CE, CCC Brand Boan Rated Voltage 300/500 V Number of Cores 1-7 Class of Conductor 1/2 Size 1.5-16 Mm2 Transport Package Heated Steel-Wooden Drum/Wooden Drum Specification SGS Trademark DingAn or OEM Origin Jiangsu Yixing, China HS Code 8544492100 Production Capacity 38000 Km/YearProduct Description
NHXMH, Electric Wire, 300/500 V, CU/XLPE/Lszh (LSOH) Cable (VDE 0250-214)Application
These cables are intended for fixed installation in dry and moist rooms as well as in masonry and concrete, in and under plaster; Not for underground installation. NHXMH-J/O are especially used in buildings with a high concentration of persons or valuable property, where improved fire characteristics are needed. This product conforms to 73/23/EW G directive (low voltage directive) CE.
Standards
VDE 0250 (part 214), VDE 0482 (part 266-2-4, test type C)
Technical Data
Conductor
Class 1 for re: Solid, round plain copper conductor, single wire to VDE0295
Class 2 for rm: Stranded, round plain copper conductor, multi wire to VDE0295
Class 2 for sm: Stranded, sectorial plain copper conductor to VDE0295
Insulation
XLPE (Cross-linked Polyethylene)
Filler
Halogen free compound
Sheath
Halogen free thermoplastic polymer compound
Temperature Rating
0° C to +70° C
Minimum Bending Radius
4 x overall diameter
Core Identification
Up to and including 5 cores:
Colour coded or number coded
7 cores and above: Number coded
| No. of Cores x Nominal Cross Sectional Area | Conductor Type | Nominal Overall Diameter | Nominal Weight |
| # x mm² | mm | kg/Km | |
| 1 x 1.5 | re | 7.0 | 49.0 |
| 1 x 2.5 | re | 7.6 | 60.0 |
| 1 x 4.0 | re | 8.6 | 80.0 |
| 1 x 6.0 | re | 9.9 | 111.0 |
| 1 x 10.0 | re | 11.2 | 160.0 |
| 1 x 16.0 | re | 11.9 | 232.0 |
| 2 x 1.5 | re | 8.9 | 110.0 |
| 2 x 2.5 | re | 10.0 | 136.0 |
| 2 x 4.0 | re | 11.4 | 202.0 |
| 3 x 1.5 | re | 9.4 | 130.0 |
| 3 x 2.5 | re | 10.4 | 163.0 |
| 3 x 4.0 | re | 11.8 | 235.0 |
| 3 x 6.0 | re | 13.4 | 323.0 |
| 3 x 10.0 | re | 16.0 | 485.0 |
| 3 x 16.0 | re | 19.7 | 850.0 |
| 4 x 1.5 | re | 10.2 | 151.0 |
| 4 x 2.5 | re | 11.3 | 200.0 |
| 4 x 4.0 | re | 13.3 | 300.0 |
| 4 x 6.0 | re | 14.8 | 400.0 |
| 4 x 10.0 | re | 17.4 | 603.0 |
| 4 x 16.0 | re | 21.6 | 940.0 |
| 5 x 1.5 | re | 10.8 | 177.0 |
| 5 x 2.5 | re | 11.9 | 238.0 |
| 5 x 4.0 | re | 14.8 | 345.0 |
| 5 x 6.0 | re | 16.0 | 475.0 |
| 5 x 10.0 | re | 18.9 | 720.0 |
| 5 x 16.0 | re | 23.8 | 1142.0 |
| 7 x 1.5 | re | 11.4 | 209.0 |
| 7 x 2.5 | re | 13.5 | 300.0 |
