Utpcat3 Connecting Cables/Communication Cable/Network Cable/Wire

Zhejiang Kuayue Cable Co., Ltd.
  • Application：LAN Cable
  • Conductor Material：BC,CCS,CCA,TC,CU,CCAG
  • Cover Material：PE
  • Type：Cat 3
  • Material Shape：Flat Wire
  • Conductor Type：Solid

Base Info

  • Model NO.：Utpcat3
  • Model：Hyyc
  • Brand：Hanli
  • Transport Package：500,1000m
  • Specification：0.4, 0.45, 0.5cu
  • Trademark：hanli
  • Origin：Zhejiang
  • HS Code：8544491100
  • Production Capacity：3000000m,Month

Description

Conductor Diametermm0.5Maximum Conductor Resistance @20°C/km91Minimum Insulation Resistance @500V DCM.km20000Maximum Resistance Unbalance%2Average Mutual CapacitancenF/km52Maximum Capacitance Unbalance @1KHz pair-to-pairpF/500m45Maximum Capacitance Unbalance @1KHz pair-to-groundpF/500m400Impedance @0.3 - 1MHz 100+/- 20Impedance @1 - 40MHz 100+/- 15Maximum Average Attenuation @0.1MHzdB/km0.81Maximum Average Attenuation @0.3MHzdB/km1.15Maximum Average Attenuation @0.6MHzdB/km1.65Maximum Average Attenuation @1MHzdB/km2.1Maximum Average Attenuation @4MHzdB/km4.3Maximum Average Attenuation @10MHzdB/km6.6Maximum Average Attenuation @16MHzdB/km8.2Maximum Average Attenuation @20MHzdB/km9.2Maximum Average Attenuation @31.25MHzdB/km11.8Maximum Average Attenuation @40MHzdB/km13.9Minimum Return Loss @1-20MHzdB/100m23Minimum Return Loss @20-40MHzdB/km23-10log (f/20)Minimum ELFEXT pair-to-pair @0.16MHzdB69Minimum ELFEXT pair-to-pair @1MHzdB55Minimum ELFEXT pair-to-pair @20MHzdB29Minimum ELFEXT pair-to-pair @40MHzdB23Minimum NEXT pair-to-pair @0.16MHzdB68Minimum NEXT pair-to-pair @1MHzdB59Minimum NEXT pair-to-pair @20MHzdB39Minimum NEXT pair-to-pair @40MHzdB35Dielectric StrengthdB Conductor to Conductor 3secsV DC3000Conductor to Screen 3secsV DC5000
Mechanical and Thermal Properties
Temperature range during operation (fixed state): -30°C - +70°C
Temperature range during installation (mobile state): -20°C - +50°C
Minimum bending radius: 10 x Overall Diameter

Utpcat3 Connecting Cables/Communication Cable/Network Cable/WireUtpcat3 Connecting Cables/Communication Cable/Network Cable/WireUtpcat3 Connecting Cables/Communication Cable/Network Cable/WireUtpcat3 Connecting Cables/Communication Cable/Network Cable/WireUtpcat3 Connecting Cables/Communication Cable/Network Cable/WireUtpcat3 Connecting Cables/Communication Cable/Network Cable/WireUtpcat3 Connecting Cables/Communication Cable/Network Cable/Wire
Welcome to visit our factory and  get our samples.
  Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.

Choose us, won't make you disappointed:
1.6years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001
6.Quick delivery time(20ft,25days)
