- Model NO.:MV-90
- Wire Core Material:Bare Copper Wire
- Certification:ISO, CCC
- Model:Mv-90
- Brand:Boan
- Rated Voltage:35 Kv
- Number of Cores:1
- Section:1,0 AWG-1000 Mcm
- Class of Conductor:B
- Insulation Level:100% or 133%
- Transport Package:Heated Steel-Wooden Drum,Steel Drum
- Specification:SGS
- Trademark:DingAn
- Origin:Jiangsu Yixing, China
- HS Code:8544601200
- Production Capacity:12000 Km,Year
100% Insulation Levels (260 mil) | 133% Insulation Levels (320 mil) |
Size | Number of Strands | Conductor Nominal | Diameter Over Insulation | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight | Diameter Over Insulation | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight |
Copper | Aluminum | Copper | Aluminum |
AWG of kcmil | | in | in | mil | in | lb/kft | in | mil | in | lb/kft |
1/0 | 19 | 0.34 | 1.06 | 80 | 1.37 | 973 | 746 | 1.21 | 80 | 1.52 | 1116 | 889 |
2/0 | 19 | 0.38 | 1.1 | 80 | 1.41 | 1087 | 801 | 1.25 | 80 | 1.56 | 1233 | 947 |
3/0 | 19 | 0.42 | 1.15 | 80 | 1.46 | 1228 | 868 | 1.30 | 80 | 1.61 | 1379 | 1018 |
4/0 | 19 | 0.48 | 1.2 | 80 | 1.51 | 1401 | 947 | 1.35 | 80 | 1.66 | 1557 | 1102 |
250 | 37 | 0.52 | 1.26 | 80 | 1.57 | 1568 | 1030 | 1.41 | 110 | 1.78 | 1832 | 1295 |
300 | 37 | 0.57 | 1.31 | 80 | 1.62 | 1758 | 1113 | 1.46 | 110 | 1.83 | 2030 | 1385 |
350 | 37 | 0.62 | 1.35 | 80 | 1.66 | 1946 | 1193 | 1.50 | 110 | 1.87 | 2225 | 1472 |
400 | 37 | 0.66 | 1.39 | 110 | 1.77 | 2235 | 1375 | 1.54 | 110 | 1.95 | 2464 | 1604 |
500 | 37 | 0.74 | 1.47 | 110 | 1.84 | 2604 | 1529 | 1.62 | 110 | 2.02 | 2843 | 1767 |
600 | 61 | 0.81 | 1.56 | 110 | 1.96 | 3036 | 1746 | 1.71 | 110 | 2.11 | 3238 | 1947 |
750 | 61 | 0.91 | 1.65 | 110 | 2.06 | 3576 | 1963 | 1.80 | 110 | 2.21 | 3787 | 2174 |
1000 | 61 | 1.06 | 1.81 | 110 | 2.21 | 4470 | 2320 | 1.96 | 110 | 2.36 | 4695 | 2545 |
